ORIGINAL INSTRUCTIONS
LAWN MOWER PETROL
FTDT461ZT
OWNER'S MANUAL
CAUTION: Read and follow all Safety Rules and Instructions before operating
this equipment
BUILDER SAS
32, rue Aristide Bergès - ZI 31270 Cugnaux - France
MADE IN PRC
1

Advertisement

Table of Contents
loading

Related Manuals for Feider Machines FTDT461ZT

Summary of Contents for Feider Machines FTDT461ZT

  • Page 1 ORIGINAL INSTRUCTIONS LAWN MOWER PETROL FTDT461ZT OWNER’S MANUAL CAUTION: Read and follow all Safety Rules and Instructions before operating this equipment BUILDER SAS 32, rue Aristide Bergès - ZI 31270 Cugnaux - France MADE IN PRC...

  • Page 2: Safety Instructions

    1. SAFETY INSTRUCTIONS Instructions Read the instructions carefully. Be familiar with the controls and proper use  of the equipment.  Never allow children to use this mower. If the mower is given to an other people, also give this manual. Also make sure that this person uses this device only after receiving the necessary instructions.
  • Page 3 monoxide emissions can be collected.  Mow only under daylight or under good artificial light. Always have a good visibility.  Avoid using the equipment on greasy grass, where possible. Always be sure of your walking on the slopes.  Walk, never run.
  • Page 4 When the tool is stopped, park it in a safe place.  Move slowly when moving.  The lawnmower should not be used in slopes and near drop-offs, ditches  or embankments; if the tool must be used in these kinds of emplacements, take an extreme precaution and operate carefully the tool.
  • Page 5 your hands or feet under the mower deck or in the rear ejection port while the engine is running. Turn off the engine and remove the spark plug cap in the following cases:  o Before operating under the mower deck or near the ejection opening. o Before any maintenance, repair or verification.
  • Page 6 Fuel Handling Use caution when handling fuels. They are flammable and the vapours are explosive. Use only an approved container. Never remove the fuel cap or add fuel while the machine is on. Turn off the unit and allow the engine and exhaust components to cool down before refuelling. Do not smoke.
  • Page 7 Symbols Read the instructions manual Risk of projections; keep bystanders away Sharp blades; Beware of cutting fingers and feet. Do not touch the blades until the tool is on a completely stop. Clean the area to be mowed, keep children and other people at a safe distance from the machine.
  • Page 8 Intended use This device is only for lawn mowing grass in the domestic area. The device is designed for domestic use. It is not intended for continuous professional use. Any other use that is not expressly permitted in this manual may result in damage to the device and constitute a serious danger to the user.
  • Page 9 Technical data FTDT461ZT Model Power 2.4 kW Engine speed 2900/min Cutting width 460mm Adjustable cutting height 6 positions Grass collection capacities 50 L 22.3 kg weight Guaranteed Sound Power Level 96 dB(A ) Sound power level Max.93 dB (A); K=2.98 dB(A) Sound pressure level Max.82,5 dB (A) K= 3 dB(A)
  • Page 10 Instruction for grass bag assembly Before using the grass catcher, the side discharge must be removed. Pull plastic loops over basket rods. Open the flap then Install the grass catcher on the hook on the rear of the tool. Release the flap. Disassemble the grass catcher Lift the flap and remove the grass catcher.

  • Page 11: Adjust Cutting Height

    Mulching kit Before using the mulching kit, the lateral discharge must be removed. Assembly Remove the grass catcher if installed. Lift the flap. Fully insert the mulching kit at the back of the tool. Press the kit to lock it in place. Disassembly Lift the flap.

  • Page 12: Filling Fuel Tank

    FILLING FUEL TANK a. Filling tank WARNING! Gasoline is extremely flammable. Store fuel in specially designed cans for this purpose. Fill the fuel tank only outdoors and before starting the engine. Do not smoke when filling the fuel tank or handling fuel. Never open the fuel tank cap and never add fuel while the engine is running or when it is hot.

  • Page 13: Operation

    Filling oil tank Open the oil tank. Fill directly the oil in the tank. Do not overfill. Close the oil tank. Wipe any spillage. Checking the oil level Check the oil level when the engine is off and horizontal. Remove the plug / dipstick from the oil tank and wipe it off. Insert the oil tank plug / dipstick into the tank neck as shown, without screwing it in, and then remove it to check the oil level.
  • Page 14 b. Stop the engine Release the bars. The engine turns off and the blade is slowed down. Wait until the complete stop of the blade. c. Mowing Self-propeller function The self-propelled mechanism engages by pressing the safety lever on the handle. Self-propelled mechanism ceases when you release this bar.

  • Page 15: Maintenance And Storage

    MAINTENANCE AND STORAGE Carry out maintenance and cleaning work when the engine is off and the spark plug are out. Risk of injury! Allow the tool to cool down before performing any maintenance or cleaning work. The engine elements are hot. Risk of burns! Wear gloves when handling the blades.
  • Page 16 Changing the Oil Have a container ready to catch the oil and remove the drain plug. We should incline machine to make sure all the oil could be go out. Once the oil has been emptied, replace the drain plug making sure that the washer is in place and wipe clean any spillages.

  • Page 17: Draining The Fuel Tank And Carburetor

    DRAINING THE FUEL TANK AND CARBURETOR 1. Place an approved gasoline container below the carburetor, and use a funnel to avoid spilling fuel. 2. Remove the drain bolt, then move the fuel valve lever to the ON position 3. After all the fuel has drained into the container, reinstall the drain bolt and washer.
  • Page 18 MAINTENANCE SCHEDULE After 8 After Once Befor After After5 SERVICE 50 h a year Mowing check and tighten nuts,  bolts and screws Check the oil / fuel level   and refill oil / fuel if necessary Clean control elements / ...

  • Page 19: Declaration Of Conformity

    ZI, 32 rue Aristide Bergès – 31270 Cugnaux - France Tel: +33 (0)5.34.502.502 Fax: +33 (0)5.34.502.503 Declares that the machines: LAWN MOWER PETROL Model: FTDT461ZT Serial No.: 20210112270-20210112387 Have been designed in compliance with the following standards: EN ISO 5395-1:2013+A1:2018 EN ISO 5395-2:2013+A1:2016+A2:2017...

  • Page 20: Warranty

    WARRANTY WARRANTY The manufacturer guarantees the product against defects in material and workmanship for a period of 2 years from the date of the original purchase. The warranty only applies if the product is for household use. The warranty does not cover breakdowns due to normal wear and tear. The manufacturer agrees to replace parts identified as defective by the designated distributor.

  • Page 21: Product Failure

    PRODUCT FAILURE WHAT TO DO IF MY MACHINE BREAKS DOWN? If you bought your product in a store: a) Empty the fuel tank. b) Make sure that your machine is complete with all accessories supplied, and clean! If this is not the case, the repairer will refuse the machine.

  • Page 22: Warranty Exclusions

    WARRANTY EXCLUSIONS THE WARRANTY DOES NOT COVER: • Start-up and setting up of the product. • Damage resulting from normal wear and tear of the product. • Damage resulting from improper use of the product. • Damage resulting from assembly or start-up not in accordance with the user manual. •...
