FIELD ADJUSTMENT GUIDES
Tillage
7000 Series Disk Harrow
Date: May 31, 2017
Document #
TLUS100C-0001B
Models Affected: 7323DH, 7326DH, 7329DH, 7330DH, 7333DH, 7336DH
General Information
Proper servicing and adjustment is key to the long life of all farm equipment. With careful and systematic
inspection of equipment, costly maintenance, time and repair can be avoided. The following information
will assist with recommended servicing and adjustments:
48474
1 of 4
Document
#TLUS100C-0001B
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for GREAT PLAINS 7000 Series
Summary of Contents for GREAT PLAINS 7000 Series
- Page 1 FIELD ADJUSTMENT GUIDES Tillage 7000 Series Disk Harrow Date: May 31, 2017 Document # TLUS100C-0001B Models Affected: 7323DH, 7326DH, 7329DH, 7330DH, 7333DH, 7336DH General Information Proper servicing and adjustment is key to the long life of all farm equipment. With careful and systematic inspection of equipment, costly maintenance, time and repair can be avoided.
- Page 2 Hydraulic Hose Hookup: Hydraulic Hose Hookup Great Plains hydraulic hoses have colored coded han- Color Function dle grips to help hook up hoses to the tractor remotes. Black Lift (2 Hoses) Hoses with the same color use the same remote.
- Page 3 Hydraulic Single Point Depth Stop Adjustment: The hydraulic depth stop will ensure a consistent depth every time the machine is lowered. 1) Prior to setting the single point depth stop, ensure that the machine is completely level front to back and side to side.
- Page 4 Heavy Coil Tine Adjustment: 1) To change the angle of the coil tine, rotate the locking pin and move the adjustment handle either forward or backwards. Moving the adjustment handle towards the rear of the machine makes the drag more aggressive while moving the handle towards the front of the machine will allow residue to flow easier.
