- Page 1 Table of Contents Index Pre-Delivery Manual 7000 Series Disk Harrow 7110DH, 7112DH & 7115DH Manufacturing, Inc. www.greatplainsmfg.com Read the operator’s manual entirely. When you see this symbol, the subsequent instructions and warnings are serious - follow without exception. Your life and the lives of others depend on it! TP-69481 Illustrations may show optional equipment not supplied with standard unit.
- Page 2 Table of Contents Index Table of Contents Index...
- Page 3 Great Plains Manufacturing, Inc. assumes no responsibility for errors or omissions. Neither is any liability assumed for damages resulting from the use of the information contained herein. Great Plains Manufacturing, Inc. reserves the right to revise and improve its products as it sees fit.
- Page 4 7000 Series Disk Table of Contents Index Great Plains | 556-427Q | 2020-01-16 Table of Contents Index...
-
Page 5: Caution, Defined
Read and understand the “Safety Decals” section of the Operators Manual. Read all instructions noted on the decals. Keep decals clean. Replace damaged, faded and illegible decals. Great Plains | 556-427Q | 2020-01-16 Table of Contents Index... -
Page 6: Children
Lower implement, put tractor in park, turn off engine, and remove the key. Secure Disk Harrow using blocks and supports provided. Detach and store Disk Harrow in an area where children normally do not play. Great Plains | 556-427Q | 2020-01-16 Table of Contents Index... -
Page 7: Tires
Wear snug-fitting clothing to avoid entanglement with moving parts. Watch out for wires, trees, etc., when folding and raising machine. Make sure all persons are clear of working area. Great Plains | 556-427Q | 2020-01-16 Table of Contents Index... -
Page 8: Covered Models
Description of Unit The 7000 Series Disk is a single section primary and secondary tillage tool. Working width ranges from 10 to 15 feet. The implement is designed to cut out and bury roots and... -
Page 9: Definitions
An orientation rose in some line art illustrations shows the directions of: Up, Back, Left, Down, Front, Right. Great Plains | 556-427Q | 2020-01-16 Table of Contents Index... -
Page 10: Address, Great Plains
Further Assistance Reduce risk and complications by first unloading Great Plains Manufacturing, Inc. wants you to be satisfied gangs and finishing attachments with your new Disk Harrow. If for any reason you do not understand any part of this manual or are otherwise dissatisfies misc. -
Page 11: Electrical Hookup
Bolts may be tightened to specs, See “Torque Values to frame, to secure in place use Gr 8 bolt and Chart” on page 14. lock nut. Figure 4 TP-69418 Frame, Hub and Wheel Great Plains | 556-427Q | 2020-01-16 Table of Contents Index... - Page 12 Secure the gang assemblies (1) to the frame (2) with the ” x 7 ” u-bolts (3) ” lock washers and ” hex Figure 5 TP-69504 Gang to Frame Assembly Great Plains | 556-427Q | 2020-01-16 Table of Contents Index...
-
Page 13: Scraper Adjustment
(1) to the scraper tube (3) and move the scraper until it is about ” from the disc blade. Scrapers are not installed on the front outer most blades. Figure 6 TP-69483 Scraper Adjustment Great Plains | 556-427Q | 2020-01-16 Table of Contents Index... - Page 14 ” x 1 ” hex bolts (21), ” flat washers, ” lock washers and ” nuts. 19. Bolts may be tightened to specs, See “Torque Values Chart” on page 14. Great Plains | 556-427Q | 2020-01-16 Table of Contents Index...
- Page 15 7000 Series Disk Table of Contents Index Assembly Figure 7 TP-69503 Hitch to Frame Assembly Great Plains | 556-427Q | 2020-01-16 Table of Contents Index...
-
Page 16: Hose Clamps
Check to be sure there is enough slack in hinge area when folding machine the first time. Figure 9 43454 Hose Clamp Assembly Great Plains | 556-427Q | 2020-01-16 Table of Contents Index... -
Page 17: Color Code, Hose
Index Assembly Hydraulic Hose Hookup 25. Great Plains hydraulic hoses are color coded to help you hookup hoses to your tractor outlets. Hoses that go to the High Pressure Fluid Hazard: same remote valve are marked with the same color. - Page 18 32. Tighten all bolts to specs, See “Torque Values Chart” on page 14. Figure 11 TP-69502 Narrow Center Lights Great Plains | 556-427Q | 2020-01-16 Table of Contents Index...
- Page 19 Double check that all bolts are tightened to specs, See “Torque Values Chart” page 14.Consult “Operator’s Manual”, for the first time field adjustments before going to the field. Great Plains | 556-427Q | 2020-01-16 Table of Contents Index...
-
Page 20: Torque Values
900-1100ft-lbs (170 lbs on 6’ Cheater) Disk Gang Torque 1 ”-5 Wheel Bolt Torque Values ”-20 (75-85ft-lbs) Wheel Bolt Torque Values ”-18 (80-90ft-lbs) Wheel Bolt Torque Values ”-18 (85-100ft-lbs) Great Plains | 556-427Q | 2020-01-16 Table of Contents Index... -
Page 21: Hydraulic Connectors
12-16 -18 ORB w/jam nut 24-33 18-24 -18 ORB straight 37-53 27-39 -16 JIC 27-41 20-30 -16 ORB w/jam nut 37-58 27-43 -16 ORB straight Great Plains | 556-427Q | 2020-01-16 Table of Contents Index... -
Page 22: Hydraulic Lift
7000 Series Disk Table of Contents Index Appendix - Reference Information Hydraulic Lift Layout TP-69495 .eps 100% Great Plains | 556-427Q | 2020-01-16 Table of Contents Index... -
Page 23: 7110Dh
7000 Series Disk Table of Contents Index Appendix - Reference Information 7110DH Layout TP-69490 .eps Great Plains | 556-427Q | 2020-01-16 Table of Contents Index... -
Page 24: 7112Dh
7000 Series Disk Table of Contents Index Appendix - Reference Information 7112DH Layout TP-69491 .eps Great Plains | 556-427Q | 2020-01-16 Table of Contents Index... -
Page 25: 7112Dh 3 Bar Spike Hr Harrow 26 7115Dh
7000 Series Disk Table of Contents Index Appendix - Reference Information 7115DH Layout TP-69493 .eps Great Plains | 556-427Q | 2020-01-16 Table of Contents Index... -
Page 26: 7110Dh 3 Bar Coiltine Harrow
7000 Series Disk Table of Contents Index Appendix - Reference Information 7110DH 3 Bar Coiltine Harrow Layout TP-69496 .eps Great Plains | 556-427Q | 2020-01-16 Table of Contents Index... -
Page 27: 7110Dh 3 Bar Spike Hr Harrow
7000 Series Disk Table of Contents Index Appendix - Reference Information 7110DH 3 Bar Spike HR Harrow Layout TP-69497 .eps Great Plains | 556-427Q | 2020-01-16 Table of Contents Index... -
Page 28: 7110Dh Finishing Reel
7000 Series Disk Table of Contents Index Appendix - Reference Information 7110DH Finishing Reel Layout TP-69489 .eps Great Plains | 556-427Q | 2020-01-16 Table of Contents Index... -
Page 29: 7112Dh 3 Bar Coiltine Harrow
7000 Series Disk Table of Contents Index Appendix - Reference Information 7112DH 3 Bar Coiltine Harrow Layout TP-69498 .eps Great Plains | 556-427Q | 2020-01-16 Table of Contents Index... - Page 30 7000 Series Disk Table of Contents Index Appendix - Reference Information 7112DH 3 Bar Spike HR Harrow Layout TP-69499 .eps Great Plains | 556-427Q | 2020-01-16 Table of Contents Index...
-
Page 31: 7112Dh Finishing Reel
7000 Series Disk Table of Contents Index Appendix - Reference Information 7112DH Finishing Reel Layout TP-69492 .eps Great Plains | 556-427Q | 2020-01-16 Table of Contents Index... -
Page 32: 7115Dh 3 Bar Coiltine Harrow
7000 Series Disk Table of Contents Index Appendix - Reference Information 7115DH 3 Bar Coiltine Harrow Layout TP-69500 .eps Great Plains | 556-427Q | 2020-01-16 Table of Contents Index... - Page 33 7000 Series Disk Table of Contents Index Appendix - Reference Information 7115DH 3 Bar Spike HR Harrow Layout TP-69501 .eps Great Plains | 556-427Q | 2020-01-16 Table of Contents Index...
-
Page 34: 7115Dh Finishing Reel
7000 Series Disk Table of Contents Index Appendix - Reference Information 7115DH Finishing Reel Layout TP-69494 .eps Great Plains | 556-427Q | 2020-01-16 Table of Contents Index... -
Page 35: Table Of Contents
