CFE -10H User Manual page 18

For series connection, please make sure the SW2 DIP switch is selected as this type.
Please make sure the SW2 DIP switch is selected correctly. If the battery is connected
in parallel mode, and SW2 DIP8 is selected at ON position, it probably leads to serious
faults, even dangerous. Meanwhile, if battery is connected in series mode, and SW2
DIP8 is selected at OFF status, serious faults and hazards probably occur.
Connecte
d battery Group
number
1 —
Master
2
Slave
Master
3 Slave 1
Slave 2
WARNING
Set of SW2
Series connection
13
138
18
138
8
18
14
Parallel connection
13
13
1
13
0
1
Address
Set (SW3)
1
2
1
3
1
2
