Features; Description & Specifications - ISSI LC-2 Operation Manual

Features

• Remotely control CANON® EF lenses
• Accurate control of Focus, and aperture
• Auto-detection of attached lens and F-number with included LC-2A lens adapter
• Interfaces for Ethernet
• Multiple devices can be connected and simultaneously controlled over a network
• Easy to use software interface
• Unlimited programmable preset capability to easily store and recall saved positions on
the lens
Description & Specifications
Power
Input
Operating Temperature
Interface
Lens inputs
Presets
Software
ECCN
The ISSI Ethernet Lens Controller (LC-2) is a control device for CANON® EF lenses
using c-mount cameras. The LC-2 can operate most CANON® EF lenses. The device is
operated via a graphical user interface and allows for preset positions of the lens to be saved and
then recalled at any time. The presets will save the position of the focus and aperture. Since the
LC-2 is an Ethernet device, it can be networked with other LC-2s or Ethernet devices. This
makes communication and physical cable connections much simpler than traditional serial lens
controllers and also allows them to be operated over a longer distance than serial devices. The IP
address of the LC-2 can be configured to match the local network.
Innovative Scientific Solutions, Inc.
85-264V, 50-60Hz
5V = 1A, 5W
0- 60 ˚C
Ethernet
1
Unlimited, programmable
Windows GUI
EAR99
