2. ADVANCED REGISTRATIO N
It is possible to connect many repeaters in a chain. In order to register another repeater, follow these steps:
1. Connect the first RP-3 to the power supply socket.
2. Press the registration button on the first RP-3 – the control light no. 3 is flashing, the control light no. 4 lights up
continuously.
3. Press the registration button on the transmitting device (e.g. C-8r or C-8rm sensor, room regulator etc.).
4. Once steps 2 and 3 have been performed properly, the device animation will change - the control light no. 3 will
light up continuously and the control light no. 4 will start flashing.
5. Connect the second RP-3 to the power supply socket.
6. Press the registration button on the second RP-3 – the control light no. 3 is flashing, the control light no. 4 lights
up continuously.
7. Once steps 5 and 6 have been performed properly, the second device animation will change after a few seconds
- the control light no. 3 will light up continuously and the control light no. 4 will start flashing, and all the control
lights on the first RP-3 will start flashing simultaneously for 5 seconds.
8. Start the registration process on the receiving device (e.g. external controller/Wi-Fi 8s / ST-2807 / ST-8s etc.).
9. If the registration has been successful, the receiving controller will display an appropriate message and all the
control lights on the second RP-3 will be flashing simultaneously for 5 seconds.
In order to register another device, follow the same steps.
NOTE
In the case of battery-powered devices, it is not advisable to create chains consisting of more than two repeaters.
NOTE
Registering STT-869 thermoelectric actuator with more than two repeaters will cause a communication error
with the controller.
IV. TECHNICAL DATA
Specification
Supply voltage
Ambient temperature
Maximum power consumption
Operating frequency
Max. transmission power
230V / +/-10%/50Hz
5°C - 50°C
< 1W
868MHz
25mW
6
Value
