MOBIFLEX
®
& LFA 3. 1 / 4. 1 Extraction Arm
For use with machines having Code Numbers:
Safety Depends on You
Lincoln arc welding and cutting
equipment is designed and built
with safety in mind. However,
your overall safety can be
increased by proper installation
... and thoughtful operation on
your part. DO NOT INSTALL,
OPERATE OR REPAIR THIS
EQUIPMENT WITHOUT READ-
ING THIS MANUAL AND THE
SAFETY PRECAUTIONS CON-
TAINED THROUGHOUT. And,
most importantly, think before
you act and be careful.
• Sales and Service through Subsidiaries and Distributors Worldwide •
Cleveland, Ohio 44117-1199 U.S.A. TEL: 888.935.3878 FAX: 216.383.8823 WEB SITE: www.lincolnelectric.com
200-M(/HE) Mobile Filter Unit
K1653-1, K1653-2, K1653-3
K2633-1, K2633-2, K2633-3, K2633-4
INSTRUCTION MANUAL
• World's Leader in Welding and Cutting Products •
Copyright © Lincoln Global Inc.
IM10120
January, 2011
Advertisement
Table of Contents
Related Manuals for Lincoln Electric MOBIFLEX 200-M/HE
Summary of Contents for Lincoln Electric MOBIFLEX 200-M/HE
- Page 1 IM10120 MOBIFLEX 200-M(/HE) Mobile Filter Unit ® January, 2011 & LFA 3. 1 / 4. 1 Extraction Arm K1653-1, K1653-2, K1653-3 For use with machines having Code Numbers: K2633-1, K2633-2, K2633-3, K2633-4 Safety Depends on You Lincoln arc welding and cutting equipment is designed and built with safety in mind.
- Page 2 351040, Miami, Florida 33135 or CSA Standard W117.2-1974. A Free copy of “Arc Welding Safety” booklet E205 is available from the Lincoln Electric Company, 22801 St. Clair Avenue, Cleveland, Ohio 44117-1199. BE SURE THAT ALL INSTALLATION, OPERATION, MAINTENANCE AND REPAIR PROCEDURES ARE PERFORMED ONLY BY QUALIFIED INDIVIDUALS.
- Page 3 SAFETY ARC RAYS can burn. ELECTRIC SHOCK can kill. 3.a. The electrode and work (or ground) circuits 4.a. Use a shield with the proper filter and cover are electrically “hot” when the welder is on. plates to protect your eyes from sparks and Do not touch these “hot”...
- Page 4 SAFETY WELDING and CUTTING CYLINDER may explode SPARKS can if damaged. cause fire or explosion. 7.a. Use only compressed cylinders 6.a. Remove fire hazards from the welding area. containing the correct shielding gas for the If this is not possible, cover them to prevent process used and properly operating the welding sparks from starting a fire.
- Page 5 SAFETY 5. Toujours porter des lunettes de sécurité dans la zone de PRÉCAUTIONS DE SÛRETÉ soudage. Utiliser des lunettes avec écrans lateraux dans les zones où lʼon pique le laitier. Pour votre propre protection lire et observer toutes les instructions et les précautions de sûreté...
- Page 6 We respond to our customers based on the best information in our possession at that time. Lincoln Electric is not in a position to warrant or guarantee such advice, and assumes no liability, with respect to such information or advice.
-
Page 7: Table Of Contents
TABLE OF CONTENTS Page Installation .......................Section A Technical Specifications .................A-1/A-2 Safety Precautions ....................A-3 General Description ..................A-3/A-4 Components....................A-4/A-5 Unpacking......................A-5 Installation .......................A-5/A-7 Balance Check ......................A-7 Operation ......................Section B Safety Precautions ....................B-1 Intended Use ......................B-1 Modifications......................B-1 General Safety.......................B-1 General Description ..................B-2/B-3 Product Combinations ...................B-3 Operation ......................B-3/B-5 Filter Maintenance Indicator ..................B-5 Filter Replacement ....................B-5... -
Page 8: Installation
INSTALLATION TECHNICAL SPECIFICATIONS - Mobiflex 200-M(/HE) Base Unit (K1653-2, K1653-3) INPUT 115V/1~/60Hz MOTOR POWER 0.75 KW (1 HP) DIMENSIONS (See Figure A.1) LENGTH (A) WIDTH (B) HEIGHT (C) 47.6 in. (1,210 mm) 31.9 in. (810 mm) 35.4 in. (900 mm) WEIGHT 200-M: 223 lbs. - Page 9 INSTALLATION TECHNICAL SPECIFICATIONS - LFA 3.1 / 4.1 Extraction Unit MODEL LFA 3.1 Mobile LFA 4.1 Mobile LFA 3.1 Mobile LFA 4.1 Mobile Manual Manual Automatic Automatic CODE # K2633-1 K2633-3 K2633-2 K2633-4 10 ft. (3 m) 13 ft. (4 m) 10 ft.
-
Page 10: Safety Precautions
LongLife filter cartridge. • K2633-2 LFA 3.1 Mobile Automatic (10 ft. extrac- The Mobiflex 200-M/HE is a portable unit suitable to be tion arm with integrated Lamp & Arc Sensor Kit) used in relatively small facilities or near sources of pol- •... -
Page 11: Components
INSTALLATION The Mobiflex 200-M/HE filter is recommended for COMPONENTS annual consumable use of approximately*: • 500 lbs (250 kg) GMAW or FCAW or GTAW MOBIFLEX 200-M(/HE) BASE UNIT • 385 lbs (175 kg) MMA or SMAW or autogeneous The Mobiflex 200-M(/HE) Base Unit consists of the fol- lowing components (See Figure A.5):... -
Page 12: Unpacking
INSTALLATION LFA 3.1 / 4.1 MOBILE MANUAL / AUTO- LFA 3.1/4.1 Mobile Manual/Automatic Extraction MATIC • (1) LFA 3.1/4.1 Extraction Arm The LFA 3.1/4.1 Mobile Manual/Automatic extraction arm consists of the following components (See Figure • (2) Bolt M8 A.6): •... - Page 13 INSTALLATION FIGURE A.9 FIGURE A.7 LFA 3.1 / 4.1 MOBILE MANUAL See Figure A.8 for steps 7-8 The supply cable inside the base swivel mount of the 7. Insert the clamping pin (A) through the hole in the Mobiflex 200-M(/HE) Base Unit is not used when post located above the split pin.
-
Page 14: Balance Check
INSTALLATION FIGURE A.10 FIGURE A.11 If the extraction hood falls on its own (See Figure A.12): • Cut the tie wrap of the rubber protection cover which LFA 3.1/4.1 MOBILE AUTOMATIC is applied over the hood hinge. The K2633-2 or K2633-4 LFA 3.1/4.1 Mobile •... - Page 15 INSTALLATION LFA 3.1/4.1 MOBILE FIGURE A.13 MANUAL/AUTOMATIC A hose running guard is attached to the middle hinge of the extraction arm by a piece of tape. See Figure A.16 1. Take the hose running guard (A) and snap it into place at the middle hinge (B).
-
Page 16: Operation
OPERATION SAFETY PRECAUTIONS WARNING WARNING Avoid using the product for filter- dust particles which released when welding surfaces treated with primer. FUMES GASES dangerous. Never use the product without pre- • Use in open, well ventilated areas filter and LongLife filter cartridge. or vent exhaust outside. -
Page 17: General Description
• K2633-4 LFA 4.1 Mobile Automatic (13 ft. extrac- able cellulose/polyester blend LongLife filter cartridge. tion arm with integrated Lamp & Arc Sensor Kit) The Mobiflex 200-M/HE is a portable unit suitable to be used in relatively small facilities or near sources of pol- MOBIFLEX 200-M BASE UNIT lution without a fixed location. -
Page 18: Product Combinations
OPERATION LFA 3.1 / 4.1 MOBILE MANUAL / • K1668-3 (1) Hose and Hood Set instead of extraction AUTOMATIC OPERATION The LFA 3.1/4.1 Mobile Manual and Mobile Automatic Extraction Arms are flexible fume extraction arms with The air which contains welding fume is captured, a 360°... - Page 19 OPERATION • Use the handles to move the Mobiflex 200-M(/HE) to MOBIFLEX 200-M(/HE) & LFA 3.1/4.1 the workplace. MOBILE AUTOMATIC • Lock the right swivel caster. See Figure B.2 and B.4 • Carefully apply the correct input power. • Press the power switch ON (See Figure B.2, item B) to activate power supply.
-
Page 20: Operation
OPERATION FIGURE B.4 WARNING Saturation or clogging of the filter cartridge results in a decrease of the extraction capacity which could result in reduced extraction of weld- ing fumes. ------------------------------------------------------------------------ • When the Filter Maintenance Indicator is entirely red, replace the LongLife filter cartridge. See Filter Replacement for description.
