1. Product Overview

1.1. Product features

BIT-V409R is an ultra HD Rotary Splicer by Shenzhen Bitvisus Technology Limited.
Support 4 channels HDMI input (1 channel 4K@60Hz, 3 channels 4K@60Hz), 1
channel DP input (4K@60Hz), 9 channels output HDMI (1080p@60Hz), 1 channel
DP loop out.
A single device, 5 inputs and 9 outputs(Compatible with 1 in 9 out), can be
combined in any number of splicing modes: horizontal screen / vertical screen /
2X2, and support large scale parallel operation in the form of loop out.
It can open 4 windows on the whole screen at most, and supports multiple window
opening modes（Single screen、PIP double screen、double screen、Four picture
segmentation）
The input supports a maximum of 3840x2160@ 60Hz and is backward compatible.
The maximum single output supports 1920x1080 @ 60Hz.
The input supports full screen rotation of 90 ° (only supported in single-picture
mode), and the output supports 180 ° rotation of the first line (only supported
when the stitching mode is two lines).
no stretching, no deformation, no need to compress the input source, the picture is
clear.
