BTSX BIT-VWC-409R Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

BIT-VWC-409R
CATALOG
1. Product Overview .......................................................................................................... 2
1.1. Product features ..................................................................................................... 2
1.2. Application scenarios ............................................................................................ 3
2. Specifications .................................................................................................................. 3
3.Operation instructions .................................................................................................. 5
3.1. Product panel description ................................................................................ 5
3.2. Remote control function description ............................................................. 8
3.3. Product connection diagram ........................................................................... 14
3.4. Definition of rows and columns ..................................................................... 15
3.5. Supported resolution ......................................................................................... 16
4. Common problems ..................................................................................................... 17
5. Appendix ........................................................................................................................ 18
5.1 Appendix 1: Arrangement of output interface .......................................... 18
深圳市比特视讯有限公司
第 1 页 共 19 页
深圳市比特视讯有限公司

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BIT-VWC-409R and is the answer not in the manual?

Questions and answers

Related Manuals for BTSX BIT-VWC-409R

Summary of Contents for BTSX BIT-VWC-409R

  • Page 1: Table Of Contents

    深圳市比特视讯有限公司 深圳市比特视讯有限公司 BIT-VWC-409R CATALOG 1. Product Overview ......................2 1.1. Product features ..................... 2 1.2. Application scenarios .................... 3 2. Specifications ........................3 3.Operation instructions ....................5 3.1. Product panel description ................5 3.2. Remote control function description ............. 8 3.3.

  • Page 2: Product Overview

    深圳市比特视讯有限公司 1. Product Overview 1.1. Product features BIT-V409R is an ultra HD Rotary Splicer by Shenzhen Bitvisus Technology Limited. Support 4 channels HDMI input (1 channel 4K@60Hz, 3 channels 4K@60Hz), 1 channel DP input (4K@60Hz), 9 channels output HDMI (1080p@60Hz), 1 channel DP loop out.

  • Page 3: Application Scenarios

    It is mainly used in industrial applications such as ultra-high-definition video surveillance, large screen walls, large advertising screens in stores, and large screens for exhibitions. 2. Specifications Product name BIT-VWC-409R Input Max. Pixel FPS 600MHz Input supports the highest resolution 3840*2160@60Hz DP signal Display port 1.2*1...
  • Page 4 深圳市比特视讯有限公司 HDMI signal HDMI 2.0*1,，HDMI 1.4 *3 Output Max. Pixel FPS 165MHz Output single screen support resolution 1920*1080@60Hz HDMI output interface HDMI 1.3 * 9 Loop out signal Display port 1.2*1 Audio output 3.5mm Headphone Remote control, RS232 serial port (can be Control method looped out) HDMI：3840*2160@60Hz...

  • Page 5: Operation Instructions

    深圳市比特视讯有限公司 3.Operation instructions 3.1. Product panel description BIT_V409R front panel A: Industrial seat, RS232 control loop out, used in cascade mode to loop out RS232 commands to the next device. B：Network interface, TCP network protocol, is used for the control system to issue instructions to control the device.
  • Page 6 深圳市比特视讯有限公司 each HDMI interface. The light indicates that the HDMI interface has a signal input. J: 1 DP input interface, 4K60 input, suitable for graphics card output on PC host or other devices. K: Audio output interface, used for audio output devices: earphones, etc. L: DP ring output interface, when multiple devices are cascaded,It acts as a DP input source for other devices or displays.
  • Page 7 深圳市比特视讯有限公司 interface.The light is on, indicating that there is a signal output from the HDMI interface. Note 1: DIP switch,when cascading, it indicates the ID number of the current device, which is set in binary. ID number Binary ID number Binary Device 1 1000...

  • Page 8: Remote Control Function Description

    深圳市比特视讯有限公司 3.2. Remote control function description Remote control panel Remote control panel description(In the case of outputting a complete image, explain the keys) [Full screen] The output screen, put together as a whole: Remote Features button Confirm key 第 8 页 共 19 页...
  • Page 9 深圳市比特视讯有限公司 Escape key Set splicing mode: row (range: 1-16) Set splicing mode: column (range: 1-16) window： The number of each screen (window) in "whole screen"， See Note 1 at the end of the form for details. source：Enter the number of the source, 1 for HDMI, 2 for DP. Cooperation【...
  • Page 10 深圳市比特视讯有限公司 R180ᵒ First line output image rotated 180 ° (only in case of 2 lines) Clone Clone mode: copy display (1x1) for each output port Note 1: [win] key meaning: window, the number of each screen (window) in the "whole screen", the corresponding screen position is as follows.
  • Page 11 深圳市比特视讯有限公司 Four screen mode:The value of the upper left screen is No. 1, the value of the lower left screen is No. 2, the value of the upper right screen is No. 3, and the value of the lower right screen is No. 4, as shown in the following figure. Remote control operation instructions The adjustment of the following two groups of parameters needs to press the [Ent] confirmation key to take effect, and the [Esc] cancel key can be pressed when the...
  • Page 12 深圳市比特视讯有限公司 screen". For example: Currently, it is [ ] PIP mode,HDMI is displayed in large screen window and DP is displayed in small screen window by default.If you need to adjust the large screen window to DP and the small screen window to HDMI,Then you need to set [Win] to “1”(window No.
  • Page 13 深圳市比特视讯有限公司 + byte 3 + byte 4 Multi pictures byte 1 + byte 2 0x66 0x04 Mode 0x00 mode + byte 3 + byte 4 Multi pictures window byte 1 + byte 2 0x66 0x05 Window Sel Source Channel specify input + byte 3 + byte 4 source...

  • Page 14: Product Connection Diagram

    深圳市比特视讯有限公司 mode: [Mode]=0, WindowSel=0 (current screen) [Mode]=1, WindowSel=0 (left picture), WindowSel=1 (right picture) [Mode]=2, WindowSel=0 (upper left screen), WindowSel=1 (lower left screen) WindowSel=2 (upper right screen), WindowSel=3 (lower right screen) [Mode]=3, WindowSel=0 (large picture), WindowSel=1 (small picture) [Mode]=4, WindowSel=0 (upper screen), WindowSel=1 (lower screen) [SourceChannel]: Input source channel selection: 0 is HDM I, 1 is HDMI 2, 2 is HDMI 3,3 is HDMI 4,4 is DP 5.

  • Page 15: Definition Of Rows And Columns

    深圳市比特视讯有限公司 2x3 mode front panel wiring diagram The board ID of the dial switch on the front panel of the current device needs to be set. 2x3 mode front panel dial switch dial method 3.4. Definition of rows and columns Definition of row and column mode based on screen dimensions 第...

  • Page 16: Supported Resolution

    深圳市比特视讯有限公司 3.5. Supported resolution Note 1: if you need to customize special single screen output resolution, please contact the company. Note 2: the support of equal scale mode and resolution is not limited to the following tables. For details, please contact the company. Form 1 BIT-V406R Equal proportion mode supported by video card application Full screen...

  • Page 17: Common Problems

    深圳市比特视讯有限公司 1920x2160@30HZ 1920x2160@60HZ 1920x1080@60HZ 3840x2160@30HZ 3840x2160@60HZ 1920x1080@60HZ 3840x1440@30HZ 5760x2160@60HZ 1920x1080@60HZ 1920x3240@30HZ 1920x3240@60HZ 1920x1080@60HZ 2816x2376@30HZ 3840x3240@60HZ 1920x1080@60HZ 1776x3996@30HZ 1920x4320@60HZ 1920x1080@60HZ 1408x3960@30HZ 1920x5400@60HZ 1920x1080@60HZ 1184x3996@30HZ 1920x6480@60HZ 1920x1080@60HZ 4. Common problems (1) What is the output resolution of the loop-out interface? Answer: if the input interface of the device is 3840x2160 resolution, the ring out DP 第...

  • Page 18: Appendix

    深圳市比特视讯有限公司 interface resolution is 3840x2160 resolution. (2) Does it support cascading mode? Answer: cascade mode is not supported. (3) Sometimes the dial code or remote control switch does not respond? Answer: Because it involves resolution switching, it takes a certain time (1s). If the display does not meet the expectations, it can be restored by power off again.
  • Page 19 深圳市比特视讯有限公司 When the image is rotated 90ᵒ: The output interface is first up then down, first left then right. As shown in Figure 3x2 mode: 第 19 页 共 19 页...
