BIT-VWC-406R
CATALOG
1. Product Overview ............................................................................................................. 2
1.1. Product features ........................................................................................................ 2
1.2. Application scenarios ............................................................................................... 3
2. Specifications .................................................................................................................... 4
3.Operation instructions ..................................................................................................... 6
3.1. Product panel description ................................................................................... 6
3.2. Remote control function description ................................................................ 10
3.3. Product connection diagram .............................................................................. 19
3.4. Definition of rows and columns ......................................................................... 21
3.5. Supported resolution ............................................................................................ 22
4. Common problems ....................................................................................................... 24
5. Appendix .......................................................................................................................... 25
5.1 Appendix 1: Arrangement of output interface ............................................... 25
深圳市比特视讯有限公司
第 1 页 共 25 页
深圳市比特视讯有限公司

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BIT-VWC-406R and is the answer not in the manual?

Questions and answers

Related Manuals for BTSX BIT-VWC-406R

Summary of Contents for BTSX BIT-VWC-406R

  • Page 1: Table Of Contents

    深圳市比特视讯有限公司 深圳市比特视讯有限公司 BIT-VWC-406R CATALOG 1. Product Overview ......................2 1.1. Product features ......................2 1.2. Application scenarios ....................3 2. Specifications ........................4 3.Operation instructions ..................... 6 3.1. Product panel description ................... 6 3.2. Remote control function description ..............10 3.3.

  • Page 2: Product Overview

    深圳市比特视讯有限公司 1. Product Overview 1.1. Product features BIT-V406R is an ultra HD Rotary Splicer by Shenzhen Bitvisus Technology Limited. Support 4 channels HDMI input (1 channel 4K@60Hz, 3 channels 4K@60Hz), 1 channel DP input (4K@60Hz), 6 channels output HDMI (1080p@60Hz), 1 channel DP loop out.

  • Page 3: Application Scenarios

    深圳市比特视讯有限公司 rotation of the first line (only supported when the stitching mode is two lines). no stretching, no deformation, no need to compress the input source, the picture is clear. Support single display mode (1x1). Support infrared remote control, serial RS232 control. Low power consumption, energy saving and environmental protection.

  • Page 4: Specifications

    深圳市比特视讯有限公司 2. Specifications Product name BIT-VWC-406R Input Max. Pixel FPS 600MHz Input supports the highest 3840*2160@60Hz resolution DP signal Display port 1.2*1 HDMI signal HDMI 2.0*1,，HDMI 1.4 *3 Output Max. Pixel FPS 165MHz Output single screen support 1920*1080@60Hz resolution HDMI output interface HDMI 1.3 * 6...
  • Page 5 深圳市比特视讯有限公司 Power consumption Power supply 12V@2A AC-DC Weight 840g Size 270mm * 122.5mm * 20mm One DP Cable Annex One 12V@2A AC-DC One remote control Power Supply 12V@2A AC-DC Warranty One year 第 5 页 共 25 页...

  • Page 6: Operation Instructions

    深圳市比特视讯有限公司 3.Operation instructions 3.1. Product panel description BIT_V406R front panel A: Industrial seat, RS232 control loop out, used in cascade mode to loop out RS232 commands to the next device. B ： Network interface, TCP network protocol, is used for the control system to issue instructions to control the device.
  • Page 7 深圳市比特视讯有限公司 host or other devices. There is an LED light next to each HDMI interface. The light indicates that the HDMI interface has a signal input. J: 1 DP input interface, 4K60 input, suitable for graphics card output on PC host or other devices. K: Audio output interface, used for audio output devices: earphones, etc.
  • Page 8 深圳市比特视讯有限公司 BIT_V406R rear panel N: Power interface, connect to 12V@2AAC-DC power supply. O: LED light (power) next to the interface.It is a power indicator. The LED lights when the device is normally powered. P: Connect the light, which means the video signal is connected normally.
  • Page 9 深圳市比特视讯有限公司 ID number Binary ID number Binary Device 1 1000 Device 9 1001 Device 2 0100 Device 10 0101 Device 3 1100 Device 11 1101 Device 4 0010 Device 12 0011 Device 5 1010 Device 13 1011 Device 6 0110 Device 14 0111 Device 7...

  • Page 10: Remote Control Function Description

    深圳市比特视讯有限公司 3.2. Remote control function description Remote control panel Remote control panel description(In the case of outputting a complete image, explain the keys) [Full screen] The output screen, put together as a whole: Remote Features button Confirm key 第 10 页 共 25 页...
  • Page 11 深圳市比特视讯有限公司 Escape key Set splicing mode: row (range: 1-16) Set splicing mode: column (range: 1-16) window： The number of each screen (window) in "whole screen"，See Note 1 at the end of the form for details. source：Enter the number of the source, 1 for HDMI, 2 for DP.
  • Page 12 深圳市比特视讯有限公司 Double screen：left and right -- > up and down （ select the input source displayed on the screen through the [Win / Src] button） Single screen rotation HDMI①--->HDMI②--->HDMI③--->HDMI④--->DP⑤ R90ᵒ Rotate the whole input image 90 ° (only in the case of single image) R180ᵒ...
  • Page 13 深圳市比特视讯有限公司 Double picture(picture in picture mode): The face value of the large picture is No. 1, and the value of the small picture is No. 2, as shown in the following figure. Double picture(Left right mode): The left screen value is No. 1, and the right screen value is No.
  • Page 14 深圳市比特视讯有限公司 Remote control operation instructions The adjustment of the following two groups of parameters needs to press the [Ent] confirmation key to take effect, and the [Esc] cancel key can be pressed when the parameter setting needs to be cancelled. (1) [ROW, COL] is a group to adjust the output splicing mode.
  • Page 15 深圳市比特视讯有限公司 in large screen window and DP is displayed in small screen window by default.If you need to adjust the large screen window to DP and the small screen window to HDMI,Then you need to set [Win] to “ 1 ” (window No. 1 means large screen window), [Src] is “...
  • Page 16 深圳市比特视讯有限公司 byte byte 2 Rotate 90 ° 0x66 0x02 Rotate90 0x00 + byte 3 + byte 4 byte byte 2 Rotate 180 ° 0x66 0x03 Rotate180 0x00 + byte 3 + byte 4 byte Multi pictures byte 2 0x66 0x04 Mode 0x00 mode...
  • Page 17 深圳市比特视讯有限公司 window size byte 2 + byte 3 + byte 4 Description of serial port instruction set: l [Row]: Stitching mode: row [Col]: Stitching mode: column l [Rotate90]: Rotate 90 ° , 0: do not rotate, 1: rotate (only supported in single-screen mode) l [Rotate180]: Rotate 180 °...
  • Page 18 深圳市比特视讯有限公司 screen) [Mode]=3, WindowSel=0 (large picture), WindowSel=1 (small picture) [Mode]=4, WindowSel=0 (upper screen), WindowSel=1 (lower screen) [SourceChannel]: Input source channel selection: 0 is HDM I, 1 is HDMI 2, 2 is HDMI 3,3 is HDMI 4,4 is DP 5. l [Position]: Choose the position of the small window in the picture-in-picture mode: 0: center, 1: upper left corner, 2: upper right corner, 3bottom left corner, 4: Bottom right corner (only supported in PIP double screen mode)

  • Page 19: Product Connection Diagram

    深圳市比特视讯有限公司 3.3. Product connection diagram 1. Instructions for single unit Take 2x3 as an example: Front panel wiring diagram 2x3 mode front panel wiring diagram The board ID of the dial switch on the front panel of the current device needs to be set. 第...
  • Page 20 深圳市比特视讯有限公司 2x3 mode front panel dial switch dial method 第 20 页 共 25 页...

  • Page 21: Definition Of Rows And Columns

    深圳市比特视讯有限公司 3.4. Definition of rows and columns Definition of row and column mode based on screen dimensions 第 21 页 共 25 页...

  • Page 22: Supported Resolution

    深圳市比特视讯有限公司 3.5. Supported resolution Note 1: if you need to customize special single screen output resolution, please contact the company. Note 2: the support of equal scale mode and resolution is not limited to the following tables. For details, please contact the company.
  • Page 23 深圳市比特视讯有限公司 1920x2160@60H 1920x2160@30HZ 1920x1080@60HZ 3840x2160@60H 3840x2160@30HZ 1920x1080@60HZ 5760x2160@60H 3840x1440@30HZ 1920x1080@60HZ 1920x3240@60H 1920x3240@30HZ 1920x1080@60HZ 3840x3240@60H 2816x2376@30HZ 1920x1080@60HZ 1920x4320@60H 1776x3996@30HZ 1920x1080@60HZ 1920x5400@60H 1408x3960@30HZ 1920x1080@60HZ 1920x6480@60H 1184x3996@30HZ 1920x1080@60HZ 第 23 页 共 25 页...

  • Page 24: Common Problems

    深圳市比特视讯有限公司 4. Common problems (1) What is the output resolution of the loop-out interface? Answer: if the input interface of the device is 3840x2160 resolution, the ring out DP interface resolution is 3840x2160 resolution. (2) Does it support cascading mode? Answer: cascade mode is not supported.

  • Page 25: Appendix

    深圳市比特视讯有限公司 5. Appendix 5.1 Appendix 1: Arrangement of output interface When the image is not rotated: the output interface is first up then down, first left then right. As shown in the following 2x3 mode: When the image is rotated 90ᵒ: The output interface is first up then down, first left then right.
