R180ᵒ First line output image rotated 180 ° (only in case of 2 lines)
Clone Clone mode: copy display (1x1) for each output port
Note 1:
[win] key meaning: window, the number of each screen (window) in the "whole
screen", the corresponding screen position is as follows.
Single screen mode: there is only one screen, and the value is fixed as number 1, as
shown below.
Double picture(picture in picture mode): The face value of the large picture is No. 1,
and the value of the small picture is No. 2, as shown in the following figure.
Double picture(Left right mode): The left screen value is No. 1, and the right screen
value is No. 2, as shown below.
Double picture(Up down mode): The upper screen value is No. 1, and the lower
screen value is No. 2, as shown below.
