mode:
[Mode]=0, WindowSel=0 (current screen)
[Mode]=1, WindowSel=0 (left picture), WindowSel=1 (right picture)
[Mode]=2, WindowSel=0 (upper left screen), WindowSel=1 (lower left screen)
WindowSel=2 (upper right screen), WindowSel=3 (lower right screen)
[Mode]=3, WindowSel=0 (large picture), WindowSel=1 (small picture)
[Mode]=4, WindowSel=0 (upper screen), WindowSel=1 (lower screen)
[SourceChannel]: Input source channel selection: 0 is HDM I, 1 is HDMI 2, 2 is HDMI
3,3 is HDMI 4,4 is DP 5.
l [Position]: Choose the position of the small window in the picture-in-picture
mode: 0: center, 1: upper left corner, 2: upper right corner, 3bottom left corner, 4:
Bottom right corner (only supported in PIP double screen mode)
l [Size]: Choose the size of the small window in the picture-in-picture mode: 0~10,
the larger the value, the larger the window supported in PIP double screen mode).

3.3. Product connection diagram

1. Instructions for single unit
Take 2x3 as an example: Front panel wiring diagram
