- Page 1 深圳市比特视讯有限公司 深圳市比特视讯有限公司 BIT-MSE-4K60-103PRO Multi screen expansion 第 1 页 共 11 页...
-
Page 2: Table Of Contents
深圳市比特视讯有限公司 Catalog 1.Overview .............................3 1.1 Product Characteristics ....................3 1.2 Application Scenario ...................... 4 2. Specifications ...........................5 3. Operation instructions ......................6 3.1 Product panel description ....................6 3.2、 Device connection ...................... 7 4. Common problem ......................... 8 4.1. Red light problems ......................8 4.2. -
Page 3: Overview
深圳市比特视讯有限公司 1.Overview 1.1 Product Characteristics 1. BIT-MSE-4K60-103PRO industrial grade high-performance product specially developed for the demand of multichannel projection fusion. It adopts DP, DVI or HDMI / DP input interface, HDBaseT standard output port, and supports chassis . 2. BIT-MSE-HDBT-103PRO Version. Higher resolution support 7680x1200@30Hz，compatible with low... -
Page 4: Application Scenario
深圳市比特视讯有限公司 1.2 Application Scenario High resolution desktop application, large screen wall, command and dispatching system, multi screen video monitoring, engineering display application, multi-channel projection, virtual reality, ring theater, large advertising wall, LCD / LED multi screen, etc. 第 4 页 共 11 页... -
Page 5: Specifications
深圳市比特视讯有限公司 2. Specifications Product name BIT-MSE-4K60-103PRO Maximum video pixel frequency input 600MHz interface Maximum video pixel frequency output 330MHz interface 3x1920X1200@60Hz; BIT-MSE-HDBT-103PRO 3x1920X1080@60Hz Highest resolution Default resolution: 3072x768@60Hz 1x DP/1x DVI/1x HDMI Input interface type 1xDP+1xDVI or 1xDP+1xHDMI (optional) Out interface type... -
Page 6: Operation Instructions
深圳市比特视讯有限公司 3. Operation instructions 3.1 Product panel description BIT-MSE-4K60-103PRO output panel A: HDMI 2.0 input B: DP 1.2 input C. D.E.: HDMI outputost. HDMI/DP(Choose one, HDMI has priority) BIT-MSE-4K60-103PRO output panel A：Power interface B：DEBUG debug port 第 6 页 共 11 页... -
Page 7: Device Connection
深圳市比特视讯有限公司 3.2、 Device connection 1) The output of computer graphics card is connected to it. 2) The output of multi screen treasure is connected to the display Device，and the serial number of the output port is connected to corresponding display screen，the maximum distance between output and display device is 120m. -
Page 8: Common Problem
深圳市比特视讯有限公司 Some splicing modes are as follows 4. Common problem 4.1. Red light problems 1. Check the power cord, the 12V power cord must be used. 2. Check the power supply(whether the voltage is stable, etc). 3. Replace other 12V power adapter and test for power adapter issues. -
Page 9: Green Light Problems
深圳市比特视讯有限公司 4.2. Green light problems 1. Input signal lamp is damaged or other faults(EDID Chip damage, etc). 2. Output signal lamp is damaged, or other faults（Computer graphics card problem, device resolution problem, secondary device problem, signal line problem, etc）. 3. When there is input（Input indicator always on ） and no output（Output indicator light flashing / off），check your computer’s graphics card for output. -
Page 10: Computer Graphics Card Problems
深圳市比特视讯有限公司 4.3. Computer graphics card problems 1. Check whether the graphics card needs additional power supply. For multi output graphics card with multiple output ports, it generally needs additional power supply. If there is an output port switch control, refer to the operation manual of the corresponding model of graphics card. -
Page 11: Display Device Problems
深圳市比特视讯有限公司 4.4. Display device problems 1. Whether the display device supports the output resolution, which can be tested by connecting the computer graphics card directly to the device. 2. Display whether the power supply of the Device is stable and turn on the signal receiving function. （Power on, search signal function, etc.）...
