Summary of Contents for BTSX BIT-MSE-U1-312
- Page 1 Shenzhen Bitvisus technology limited. Video News Co., Ltd Shenzhen Bitvisus technology limited. Video News Co., Ltd BIT-MSE-U1-312 Ultra HD splicing processor 第 1 页 共 12 页...
-
Page 2: Table Of Contents
Shenzhen Bitvisus technology limited. Video News Co., Ltd CATALOG 1. Product Overview ............... 3 1.1. Product features ..............3 2. Specifications ................4 3.Operation instructions ............... 6 3.1. Device Connection ............6 4. Common problems ..............7 4.1. Device problem ..............7 4.2. -
Page 3: Product Overview
Shenzhen Bitvisus technology limited. Video News Co., Ltd 1. Product Overview 1.1. Product features BIT-MSE-U1-312 industrial-grade high-performance product, and its ultra-high-definition resolution supports even up to 8Kx2K@60Hz. 2. Maximum support 3 inputs and 12 outputs. All splicing modes within 12 screens can be combined arbitrarily: horizontal screens / vertical screens / odd-numbered screens splicing, and supports large-scale parallel use. -
Page 4: Specifications
LCD/LED multi-screens, etc. 2. Specifications BIT-MSE-U1-312 Ultra HD splicing Product name processor Input Max. Pixel FPS 600MHz Output Max. Pixel FPS... - Page 5 Shenzhen Bitvisus technology limited. Video News Co., Ltd 3x5 highest resolution 9600x3240@30Hz 5x3 highest resolution 5760x5400@30Hz 2x5 highest resolution 9600x2160@60Hz 5x2 highest resolution 3840x5400@60Hz 16x1 highest resolution 30720x1080@60Hz 1x16 highest resolution 1920x17280@60Hz 1x5 highest resolution 9600x1080@60Hz 1x7 highest resolution 13440x1080@60Hz Factory default 3840x2160@60Hz...
-
Page 6: Operation Instructions
3.1. Device Connection 1) Connect the output of the computer graphics card to the input of BIT-MSE-U1-312. 2) Connect the BIT-MSE-U1-312 output to the display device, and each output port serial number should be connected to the corresponding display screen. -
Page 7: Common Problems
Shenzhen Bitvisus technology limited. Video News Co., Ltd 4. Common problems 4.1. Device problem 4.1.1 Red light problem 1. Check the power cord, 220V power cord should be used for power supply. 2. Test whether the power supply to the device is stable (whether the voltage is stable, etc.). - Page 8 Shenzhen Bitvisus technology limited. Video News Co., Ltd 4. The equipment light is damaged, or other equipment malfunctions. 5. The line we provide should be use as the data line for equipment input . 第 8 页 共 12 页...
- Page 9 Shenzhen Bitvisus technology limited. Video News Co., Ltd 4.1.2 Green light problem 1. The input signal light is damaged, or other failures (EDID chip damage, etc.). 2. The input signal light is damaged, or other failures (computer graphics card problem, device resolution problem, secondary device problem, and signal line problem, etc).
-
Page 10: Computer Graphics Card Problem
Shenzhen Bitvisus technology limited. Video News Co., Ltd 4.2. Computer graphics card problem 1. Check whether the graphics card needs additional power supply. Multi-output graphics cards with multiple output ports generally require additional power supply. Whether there is output port switch control, please refer to the instruction manual of the corresponding graphics card. -
Page 11: Display Device Problem
Shenzhen Bitvisus technology limited. Video News Co., Ltd 4.3. Display device problem 1. In order to confirm whether the display device supports the output resolution, you can directly connect the computer graphics card to the device to test this resolution. 2. -
Page 12: Problem Solve
Shenzhen Bitvisus technology limited. Video News Co., Ltd 4.4. Problem solve Precondition Problem How to solve phenome The output Image is Set computer properties, set to resolution is blue "tiled" in desktop properties correct Integrated No image Change the discrete graphics card, Graphics output or contact a technician...
