ST X-LINUX-NFC5 Quick Start Manual page 9

• Connect the Discovery Kit to the Internet / Intranet via LAN or Wi-Fi and use ssh commands for accessing the board or scp
command for transferring files. Any alternate method can be used for file transfer / access. For example, below steps need
to be executed on TERA-TERM :
• Connect the Discovery Kit to your PC via USB type-A to type-micro B cable.
• Check the Virtual COM port number visible in the device manager. For example, in below snapshot, the COM port
number is 14.
• Open Tera-Term on your PC and select the COM port (as found in step 3 above). The baud rate should be 115200 baud.
The virtual terminal (remote access) will appear.
• To transfer a file from host PC to Discovery Kit, click on File menu on top left corner of the Tera-Tem window and go to
File>>Transfer>>ZMODEM>>Send. The select desired file for sending it to the /usr location of Discovery Kit. Below
snapshots -
Transfer files from PC to Discovery Kit
Setup (2/2)
9
