Global Laser LaserLyte User Manual

2. PRODUCT OPERATION
- V R ANGE
The LaserLyte system has been designed to be plug and play, to operate the system please
follow the instructions below:
1. Connect the DC jack lead (as shown in diagram B) to the back of the laser module (as
shown in diagram A)
2. Connect the other end of the lead into the PS-1 / PS-4 power supply
3. If you have more than one laser follow instruction 1 and 2 until all the lasers have
been connected to the power supply. (You will need a PS-4 to power more than one
LaserLyte laser.)
- GREENLYTE R ANGE
The GreenLyte system has been designed to be plug and play, to operate the system please
follow the instructions below:
1. Connect the DC jack lead to the back of the laser module
2. Connect the other end of the lead into the PS-1 power supply
Please note if you would like more than one GreenLyte system to be powered additional PS-1
power supplies must be purchased.
3. FOCUS ADJUSTMENT
- V R ANGE
The focus of the laser can be adjusted by using the supplied focus key (as shown in diagram H).
Should you need to adjust the focus please follow the simple instructions below:
1. Insert focus key into focus hole on laser barrel (as shown in diagram C)
2. Turn until desired focus is achieved (if the key turns to maximum limit re-insert and
continue to turn until focus is achieved)
LaserLyte
User Guide
1. PRODUCT OVERVIEW
Thank you for purchasing the LaserLyte alignment
system. The system comprises of a robust
industrial grade laser alignment module, mounting
bracket, power supply and electrical lead. The
system is ready to install in a wide variety of
positioning applications.
If you have any problems or require help when
using the LaserLyte system please call us
on +44 (0)1495 212213 or contact your local
representative.
Technology Center, Cwmtillery Industrial Estate, Abertillery Gwent. NP13 1LZ
T: +44 (0)1495 212213 F: +44 (0)1495 214004
E: sales@globallasertech.com W: www.globallasertech.com
