Richmond GTR055 Instruction Manual

GTR055
Wireless Keypad
Instruction Manual
Compatible with the following Richmond motors.
Sliding / Cantilever Motors
✓
GTR156 & GTR212
!
GTR099
!
GTR500 & GTR501
!
Compatible when used with GTR197 external receiver

Technical Specs:

4 Channel Wireless Keypad – Frequency 433.92 Mhz
•
•
Range: 30 metres (direct line of sight).
•
Power Supply: 2 x AAA (1.5v) batteries.
•
IP44 rating. Suitable for outdoor use.

Factory default PIN codes

Channel 1 - 1111
The keypad can be used for multiple PIN codes on a single gate, or to access multiple gate/garage motors.

How to pair the keypad to your gate opener:

1. Press the "LEARN" button on the Control Board of your Gate Opener until the "LEARN" LED on the control board lights up.
Please note: release the learn button once the LED on the control board lights up. If held for too long it will erase all paired remotes.
2. Enter the 4-digit PIN code for the channel you wish to pair to your motor – eg: 1111 for channel 1
3. The Green LED will flash briefly on the top of the keypad.
4. Once the green LED goes out, enter the 4-digit PIN code a second time.
5. The "LEARN" LED on your control board will flash 2 – times and then turn off.
6. The keypad has now been paired
7. To open the gate, input the 4-digit PIN code
Repeat this process for the remaining channels, using the default PIN for each channel.
GTR061 & GTR207
Swing Motors
!
GTR058 GTR062 & GTR078
GTR502 & GTR503
Channel 2 – 2222 Channel 3 – 3333
GTR053 wireless gate keypad manual – revision 1
✓
!
!
Channel 4 - 4444 Master - 999999
1
