SELECT VEHICLE
PRINT PAGES NEEDED
HOW TO USE THIS INSTALL GUIDE
1
Open the Bookmarks menu and find your vehicle OR scroll
down until you find the install guide for your vehicle.
2
Print only the pages for your vehicle using the advanced
options in the Print menu.
3
Install your Maestro RR according to the guide for your vehicle.
Pressing the printer icon or "quick printing" this document will print
NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certifi ed technician. Logos and trademarks used here in
are the properties of their respective owners.
WARNING
all of the guides in this compilation.

Advertisement

loading

Related Manuals for iDataLink Maestro RR

Summary of Contents for iDataLink Maestro RR

  • Page 1 Print only the pages for your vehicle using the advanced options in the Print menu. Install your Maestro RR according to the guide for your vehicle. WARNING Pressing the printer icon or “quick printing” this document will print all of the guides in this compilation.
  • Page 2 InstallIng 7 Inch screen RETAINS STEERING WHEEL CONTROLS, CAMERA AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR Radio Replacement Interface Click here for: iDatalink Maestro MUS2 Dash Kit Radar Installation Guides E L E C T R O N I C S...
  • Page 3 Ford Mustang InstallIng 7 Inch screen 2015-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 4 10. Remove the the two (2) 7mm screws at top of radio bezel. Pull outward on radio bezel to release the clips securing it to the dash, disconnect harnesses and remove. (Fig. 1.9) Fig. 1.7 Fig. 1.8 Fig. 1.9 Automotive Data Solutions Inc. © 2023 ADS-RR(SR)-MUS2H-DS-IG-EN maestro.idatalink.com...
  • Page 5 Then, remove the lower radio controls. (Fig. 1.15) 17. Using a small fl at head screwdriver, release the 2 clips securing the 12V power port into the bezel. (Fig. 1.16) Fig. 1.14 Fig. 1.15 Fig. 1.16 Automotive Data Solutions Inc. © 2023 ADS-RR(SR)-MUS2H-DS-IG-EN maestro.idatalink.com...
  • Page 6 Then, remove the lower radio controls. (Fig. 1.15) 17. Using a small fl at head screwdriver, release the 2 clips securing the 12V power port into the bezel. (Fig. 1.16) Fig. 1.14 Fig. 1.15 Fig. 1.16 Automotive Data Solutions Inc. © 2023 ADS-RR(SR)-MUS2H-DS-IG-EN maestro.idatalink.com...
  • Page 7 Then, remove the lower radio controls. (Fig. 1.15) 17. Using a small fl at head screwdriver, release the 2 clips securing the 12V power port into the bezel. (Fig. 1.16) Fig. 1.14 Fig. 1.15 Fig. 1.16 Automotive Data Solutions Inc. © 2023 ADS-RR(SR)-MUS2H-DS-IG-EN maestro.idatalink.com...
  • Page 8 MIC 1 MIC 1 N.C. MIC 2 MIC 2 N.C. N.C. BLACK STEP 6 STEP 4 MAESTRO RR MODULE OEM SCREEN HARNESS YELLOW AMP TURNON AMP TURNON N.C. MUS2 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE Automotive Data Solutions Inc. © 2023 ADS-RR(SR)-MUS2H-DS-IG-EN maestro.idatalink.com...
  • Page 9 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-RR(SR)-MUS2H-DS-IG-EN maestro.idatalink.com...
  • Page 10 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-RR(SR)-MUS2H-DS-IG-EN maestro.idatalink.com...
  • Page 11 The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
  • Page 12 InstallIng 7 Inch screen RETAINS STEERING WHEEL CONTROLS, CAMERA AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR Radio Replacement Interface Click here for: iDatalink Maestro MUS2 Dash Kit Radar Installation Guides E L E C T R O N I C S...
  • Page 13 Ford Mustang InstallIng 7 Inch screen 2018-2023 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 14 10. Remove the the two (2) 7mm screws at top of radio bezel. Pull outward on radio bezel to release the clips securing it to the dash, disconnect harnesses and remove. (Fig. 1.9) Fig. 1.7 Fig. 1.8 Fig. 1.9 Automotive Data Solutions Inc. © 2023 ADS-RR(SR)-MUS2H-DS-IG-EN maestro.idatalink.com...
  • Page 15 Fig. 1.12 Fig. 1.13 16. Using a small fl at head screwdriver, release the 2 clips securing the 12V power port into the bezel. (Fig. 1.16) Fig. 1.14 Fig. 1.15 Fig. 1.16 Automotive Data Solutions Inc. © 2023 ADS-RR(SR)-MUS2H-DS-IG-EN maestro.idatalink.com...
  • Page 16 Fig. 1.12 Fig. 1.13 16. Using a small fl at head screwdriver, release the 2 clips securing the 12V power port into the bezel. (Fig. 1.16) Fig. 1.14 Fig. 1.15 Fig. 1.16 Automotive Data Solutions Inc. © 2023 ADS-RR(SR)-MUS2H-DS-IG-EN maestro.idatalink.com...
  • Page 17 Fig. 1.12 Fig. 1.13 16. Using a small fl at head screwdriver, release the 2 clips securing the 12V power port into the bezel. (Fig. 1.16) Fig. 1.14 Fig. 1.15 Fig. 1.16 Automotive Data Solutions Inc. © 2023 ADS-RR(SR)-MUS2H-DS-IG-EN maestro.idatalink.com...
  • Page 18 SYNC HARNESS MIC 1 MIC 1 N.C. MIC 2 MIC 2 N.C. YELLOW STEP 5 BLACK MAESTRO RR MODULE AMP TURNON AMP TURNON N.C. MUS2 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE Automotive Data Solutions Inc. © 2023 ADS-RR(SR)-MUS2H-DS-IG-EN maestro.idatalink.com...
  • Page 19 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-RR(SR)-MUS2H-DS-IG-EN maestro.idatalink.com...
  • Page 20 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-RR(SR)-MUS2H-DS-IG-EN maestro.idatalink.com...
  • Page 21 The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
  • Page 22 InstallIng 8 or 9 Inch screen RETAINS STEERING WHEEL CONTROLS, CAMERA AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR Radio Replacement Interface Click here for: iDatalink Maestro MUS2 Dash Kit Radar Installation Guides E L E C T R O N I C S...
  • Page 23 Ford Mustang InstallIng 8 or 9 Inch screen 2015-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 24 10. Remove the the two (2) 7mm screws at top of radio bezel. Pull outward on radio bezel to release the clips securing it to the dash, disconnect harnesses and remove. (Fig. 1.9) Fig. 1.7 Fig. 1.8 Fig. 1.9 Automotive Data Solutions Inc. © 2023 ADS-RR(SR)-MUS2H-DS-IG-EN maestro.idatalink.com...
  • Page 25 Fig. 1.16 Fig. 1.17 on the radio brain, secure with ISO screws provided with aftermarket radio. (Fig. 1.17) Fig. 1.18 Fig. 1.19 Automotive Data Solutions Inc. © 2023 ADS-RR(SR)-MUS2H-DS-IG-EN maestro.idatalink.com...
  • Page 26 Fig. 1.16 Fig. 1.17 on the radio brain, secure with ISO screws provided with aftermarket radio. (Fig. 1.17) Fig. 1.18 Fig. 1.19 Automotive Data Solutions Inc. © 2023 ADS-RR(SR)-MUS2H-DS-IG-EN maestro.idatalink.com...
  • Page 27 Fig. 1.16 Fig. 1.17 on the radio brain, secure with ISO screws provided with aftermarket radio. (Fig. 1.17) Fig. 1.18 Fig. 1.19 Automotive Data Solutions Inc. © 2023 ADS-RR(SR)-MUS2H-DS-IG-EN maestro.idatalink.com...
  • Page 28 MIC 1 MIC 1 N.C. MIC 2 MIC 2 N.C. N.C. BLACK STEP 6 STEP 4 MAESTRO RR MODULE OEM SCREEN HARNESS YELLOW AMP TURNON AMP TURNON N.C. MUS2 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE Automotive Data Solutions Inc. © 2023 ADS-RR(SR)-MUS2H-DS-IG-EN maestro.idatalink.com...
  • Page 29 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-RR(SR)-MUS2H-DS-IG-EN maestro.idatalink.com...
  • Page 30 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-RR(SR)-MUS2H-DS-IG-EN maestro.idatalink.com...
  • Page 31 The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
  • Page 32 InstallIng 8 or 9 Inch screen RETAINS STEERING WHEEL CONTROLS, CAMERA AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR Radio Replacement Interface Click here for: iDatalink Maestro MUS2 Dash Kit Radar Installation Guides E L E C T R O N I C S...
  • Page 33 Ford Mustang InstallIng 8 or 9 Inch screen 2018-2023 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 34 10. Remove the the two (2) 7mm screws at top of radio bezel. Pull outward on radio bezel to release the clips securing it to the dash, disconnect harnesses and remove. (Fig. 1.9) Fig. 1.7 Fig. 1.8 Fig. 1.9 Automotive Data Solutions Inc. © 2023 ADS-RR(SR)-MUS2H-DS-IG-EN maestro.idatalink.com...
  • Page 35 19. Install factory brackets to aftermarket radio brain aligning the center hole of the backets with the mounting locations on the radio brain, secure with ISO screws provided with aftermarket radio. (Fig. 1.18) Fig. 1.16 Fig. 1.17 Fig. 1.18 Automotive Data Solutions Inc. © 2023 ADS-RR(SR)-MUS2H-DS-IG-EN maestro.idatalink.com...
  • Page 36 19. Install factory brackets to aftermarket radio brain aligning the center hole of the backets with the mounting locations on the radio brain, secure with ISO screws provided with aftermarket radio. (Fig. 1.18) Fig. 1.16 Fig. 1.17 Fig. 1.18 Automotive Data Solutions Inc. © 2023 ADS-RR(SR)-MUS2H-DS-IG-EN maestro.idatalink.com...
  • Page 37 19. Install factory brackets to aftermarket radio brain aligning the center hole of the backets with the mounting locations on the radio brain, secure with ISO screws provided with aftermarket radio. (Fig. 1.18) Fig. 1.16 Fig. 1.17 Fig. 1.18 Automotive Data Solutions Inc. © 2023 ADS-RR(SR)-MUS2H-DS-IG-EN maestro.idatalink.com...
  • Page 38 SYNC HARNESS MIC 1 MIC 1 N.C. MIC 2 MIC 2 N.C. YELLOW STEP 5 BLACK MAESTRO RR MODULE AMP TURNON AMP TURNON N.C. MUS2 T-HARNESS NOT REQUIRED STEERING WHEEL CONTROL CABLE Automotive Data Solutions Inc. © 2023 ADS-RR(SR)-MUS2H-DS-IG-EN maestro.idatalink.com...
  • Page 39 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-RR(SR)-MUS2H-DS-IG-EN maestro.idatalink.com...
  • Page 40 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-RR(SR)-MUS2H-DS-IG-EN maestro.idatalink.com...
  • Page 41 The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
