- Page 1 Operator’s Manual MME30-RJ ART_5993 Serial Number Range Part # 96264 18300000 - Up April 2023...
-
Page 2: Revision History
April 2023 Revision History Date Reason for Update March 2023 New Release MEC Aerial Work Platforms 1401 S. Madera Avenue, Kerman, CA 93630 USA Toll Free: 1-877-632-5438 Phone: 1-559-842-1500 Fax: 1-559-842-1520 info@MECawp.com www.MECawp.com Page i MME30-RJ - Operator’s Manual... - Page 3 � � � � � � � � � 33 Serial Plate � � � � � � � � � � � � � � � � � � � � � 35 Page ii MME30-RJ - Operator’s Manual...
- Page 4 Your MEC Aerial Work Platform has been designed, built, and tested to provide safe, dependable service. Only authorized, trained and qualified personnel shall be allowed to operate or service the machine.
- Page 5 For your safety and the safety of those around you, you must operate your machine as instructed in this manual. MEC designs aerial work platforms to safely and reliably position personnel, along with their necessary tools and materials, at overhead work locations. The owner/user/operator of the machine should not accept responsibility for the operation of the machine unless properly trained.
- Page 6 Section 2 - Safety April 2023 Safety Alert Symbols & Fall Protection MEC manuals and decals use symbols, colors and signal words to help you recognize important safety, operation and maintenance information. RED and the word DANGER – Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.
-
Page 7: Specifications
Working Height adds 6 feet (2 m) to platform height. Maximum sound level at normal operating workstations (A-weighted) Slope rating is subject to ground conditions and adequate traction. Floor loading information is approximate and does not incorporate different option configurations. Page 4 MME30-RJ - Operator’s Manual... - Page 8 An operator must not use drugs or alcohol that can change his/her alertness or coordination. An operator on prescription or over-the-counter drugs needs medical advice on whether or not he/she can safely operate machines. Page 5 MME30-RJ - Operator’s Manual...
- Page 9 Such persons shall be capable of working safely on energized circuits and shall be familiar with the proper use of special precautionary techniques, personal protective equipment, insulating and shielding materials and insulated tools. Page 6 MME30-RJ - Operator’s Manual...
- Page 10 (b) Transmission lines greater than 133 kV LEGEND = No shading, in the front views, indicates no proximity requirements = Light shading indicates spotter is required = Heavy shading indicates the NO GO ZONE ART_3265 Page 7 MME30-RJ - Operator’s Manual...
- Page 11 Use extreme care and slow speeds while driving the machine in the stowed position across uneven terrain, debris, unstable or slippery surfaces, and near holes or drop-offs. Page 8 MME30-RJ - Operator’s Manual...
- Page 12 Keep hands and limbs out of the mast. Keep hands clear when lowering rails. Do not work under the platform. Use common sense and planning when operating the machine with the controller from the ground. Maintain safe distances between the operator, the machine and fixed objects. Page 9 MME30-RJ - Operator’s Manual...
- Page 13 Be aware of limited sight distance and blind spots when driving or ART_6000G operating the machine. The machine must be on a firm and level surface or secured before releasing the brakes. Page 10 MME30-RJ - Operator’s Manual...
- Page 14 Conduct a thorough pre-operation inspection of the machine and test all functions before each work shift. Immediately tag and remove from service a damaged or malfunctioning machine. Make sure all maintenance has been performed as specified in the Service & Parts manual. Page 11 MME30-RJ - Operator’s Manual...
- Page 15 Connect the battery charger to a grounded, AC 3-wire electrical outlet only. Inspect daily for damaged cords, cables and wires. Replace damaged items before operating. Avoid electrical shock from contact with battery terminals. Remove all rings, watches and other jewelry. Page 12 MME30-RJ - Operator’s Manual...
- Page 16 3. Rotate the turntable so that the platform is between the non-steer wheels. 4. Turn the key switch to the “OFF” position and remove the key to secure from unauthorized use. 5. Push in the red Emergency Stop buttons to the “OFF” position. Page 13 MME30-RJ - Operator’s Manual...
-
Page 17: Section 5 - Components And Controls
15) Mast 16) Flashing Beacon 17) Cable Reel 18) Tie-Down/Lift Points 19) Hydraulic Power Unit 20) Motor Controllers 21) Batteries 22) Platform Electrical Outlet 23) Hydraulic Oil Tank ILLUSTRATION No. ART_5999 24) Manual Box Page 14 MME30-RJ - Operator’s Manual... -
Page 18: Upper Controls
When the Drive Function is selected, press the thumb rocker switch to control the steer wheels. 8 Thumb Rocker Switch When the Mast/Turntable Select, press the thumb rocker switch to rotate the turntable. 9 Function Enable Switch Function Enable Switch for LIFT, DRIVE/STEER, ROTATE, and JIB functions. Page 15 MME30-RJ - Operator’s Manual... -
Page 19: Base Controls
Press the first button to go up the Menu items. 8 Menu Buttons Press the second button to go down the Menu items. Press the third button to exit the Menu screen. Press the fourth button to enter the Menu screen Page 16 MME30-RJ - Operator’s Manual... - Page 20 Scheduled maintenance inspections shall be performed by qualified service technicians, according to the manufacturer’s specifications and the requirements listed in the Service & Parts manual. Page 17 MME30-RJ - Operator’s Manual...
- Page 21 Cracks in welds or structural components Dents or damage to machine Be sure that all structural and other critical components are present and all associated fasteners and pins are in place and properly tightened. Page 18 MME30-RJ - Operator’s Manual...
- Page 22 Overhead obstructions and high voltage conductors • Hazardous locations • Inadequate surface support to withstand all load forces imposed by the machine • Wind and weather conditions • The presence of unauthorized personnel • Other possible unsafe conditions Page 19 MME30-RJ - Operator’s Manual...
-
Page 23: Maintenance Inspection Report
Limit switches slows drive when elevated Retractile Cord Reel operational Indoor/Outdoor limit switch set, test operation Emergency Stop, stops power/operation Pothole switch test Key Switch, proper operation Battery Charger operation Battery Switch, stops all power Amber Beacon, Operation Page 20 MME30-RJ - Operator’s Manual... -
Page 24: Function Tests
9. Turn left and hold the function select switch to select the Mast Lifting/Lowering function, then move the movement select switch up/down. • Result: The Mast Lifting/Lowering function should operate through a full cycle. The descent alarm should sound while the mast is lowering/rising. Page 21 MME30-RJ - Operator’s Manual... - Page 25 25. Press and hold the function enable switch on the control handle. Move the control handle in the direction indicated by the red arrow. • Result: The mast should lower. The descent alarm should sound while the mast is lowering. Page 22 MME30-RJ - Operator’s Manual...
- Page 26 Result: If the drive speed with the platform raised exceeds 5.5 inches (14 cm) per second, immediately tag and remove the machine from service. 40. Lower the mast. Raise the jib boom until the platform floor is approximately 4.9 ft (1.5 m) from Page 23 MME30-RJ - Operator’s Manual...
- Page 27 Result: The platform continued to rise to a height of about 30 ft (9.1 m). 59. Turn the Indoor/Outdoor select switch to the Outdoor mode side. • Result: The alarm should sound. 60. Turn the Indoor/Outdoor select switch to the Indoor mode side and fully lower the platform. Page 24 MME30-RJ - Operator’s Manual...
- Page 28 79. Use the wrench to hold the button, and then move the handle up and down. • Result: The tires steer to the right. Note: When the cover cannot be opened in special position, remove the cover and then use manual operation. Page 25 MME30-RJ - Operator’s Manual...
-
Page 29: Section 9 - Operating Instructions
• Select to limit the maximum height when exposed to wind. Overload Indicator Light ILLUSTRATION No. ART_6082 Indicates too much weight on the platform. Remove weight from the platform to restore function and continue. Page 26 MME30-RJ - Operator’s Manual... - Page 30 Emergency Stop button clockwise to the “ON” position. ART_4989 To Position Platform 10. Push and hold the appropriate function button. 11. Press and hold the movement select switch. Note: Drive and steer functions are not available from the ground controls. Page 27 MME30-RJ - Operator’s Manual...
- Page 31 Manual Operating To raise the Mast 28. Open the turntable cover opposite the ground controls. 29. Locate the mast function valve on the function manifold. 30. Insert the manual hand pump handle into the pump. Page 28 MME30-RJ - Operator’s Manual...
- Page 32 Rise = 12 in / 0.3 m (0.3 m ÷ 3.6 m = 0.083 × 100 % = 8.3%) RISE If the slope exceeds the maximum slope or side slope rating, the machine must be winched or transported up or down the slope. See ART_4983 Transport and Lifting section. Page 29 MME30-RJ - Operator’s Manual...
-
Page 33: Battery And Charger Instructions
“W4” or “W27” alarm code during work. During the charging process if temperatures are consistently higher than 104°F (40°C) or lower than 59°F (15°C), stop charging to check whether the battery and charger are normal. Page 30 MME30-RJ - Operator’s Manual... -
Page 34: Transport And Lifting Instructions
Inspect the entire machine for loose or unsecured items. ART_6025 Securing the Chassis Use chains of ample load capacity. Use a minimum of 4 chains. Adjust the rigging to prevent damage to the chains. Page 31 MME30-RJ - Operator’s Manual... - Page 35 5. Rust protection • Inspect the paint before the machine is stored and repaint if necessary. The machine can not be used until it has been inspected and maintained according to the daily check procedure. Page 32 MME30-RJ - Operator’s Manual...
- Page 36 MME30-RJ 2/9/2023 Section 12 - Decals April 2023 Decals Decals 8* *Inside right steel cover. Page 33 MME30-RJ - Operator’s Manual...
- Page 37 Qty. - 1 46733 Qty. - 1 46731 Qty. - 2 46774 Qty. - 1 8911 Qty. - 1 96269 Qty. - 1 94114 Qty. - 1 41652 Qty. - 1 47404 Qty. - 1 Page 34 MME30-RJ - Operator’s Manual...
-
Page 38: Serial Plate
MAX LOAD PER WHEEL: The maximum safe weight applied to each wheel. Calculated with all available options installed. Fw = 30% (Wm + Wc + Wopt) CHASSIS INCLINATION: The angle at which the tilt alarm sounds. Page 35 MME30-RJ - Operator’s Manual... - Page 39 April 2023 Notes Page 36 MME30-RJ - Operator’s Manual...
- Page 40 April 2023 Notes Page 37 MME30-RJ - Operator’s Manual...
- Page 41 April 2023 Notes Page 38 MME30-RJ - Operator’s Manual...
- Page 42 MEC Parts Order Form Phone: 559-842-1523 Fax: 559-400-6723 Email: Parts@mecawp.com Please Fill Out Completely: Date: Ordered By: Account: Your Fax No: Bill to: Ship to: Purchase Order Number Ship VIA ** All orders MUST have a Purchase Order Number **Fed Ex shipments require Fed Ex account number...
-
Page 43: Limited Owner Warranty
MEC Aerial Platform Sales Corp. and is found upon inspection by MEC Aerial Platform Sales Corp. to be defective in material and/or workmanship. MEC Aerial Platform Sales Corp. shall not be liable for any consequential, incidental or contingent damages whatsoever. - Page 44 MEC Aerial Work Platforms 1401 S. Madera Avenue, Kerman, CA 93630 USA Toll Free: 1-877-632-5438 Phone: 1-559-842-1500 Fax: 1-559-842-1520 info@MECawp.com www.MECawp.com...
