VEK S4C Manual
VEK S4C
Traffic Detector -
2023-04-24
S4C_Manual_en_5.docx

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VEK S4C and is the answer not in the manual?

Questions and answers

Related Manuals for Feig Electronic VEK S4C

Summary of Contents for Feig Electronic VEK S4C

  • Page 1 VEK S4C Manual VEK S4C Traffic Detector - 2023-04-24 S4C_Manual_en_5.docx...
  • Page 2 Photocopying and reproduction of this guide in whole or in part as well as translations into other languages are not permitted without prior written permission from FEIG ELECTRONIC. Also prohibited is storage of this guide in whole or in part on modern storage devices for the purposes of further processing in data processing systems.

  • Page 3: Table Of Contents

    Opto coupler Outputs ........................24 Fault Output ............................24 7.10 PE connection ........................... 24 Accessories ............................25 VEK S4C – connection kit ......................... 25 Service software ..........................25 Safety instructions and warnings ......................26 10 Functions in 4-channel mode ........................ 27 10.1 Scanning speed (4Ch) ........................

  • Page 4: Functional Description

    VEK S4C Functional Description The VEK S4C traffic detector is a dual system for inductive detection of vehicles. Information about speed, length and class of a vehicle can be provided using the measuring system (two loop principle) and its evaluation. The data determined in this way are assembled in a data protocol and provided to a higher level system (host computer) for further evaluation.

  • Page 5: Vehicle Detection

    Longer calibration times are caused by frequency instabilities; their causes must be determined and remedied. 1.3 Classification of vehicles The VEK S4C detector has two classification modules for vehicle detection. These can be parameterised independently from each other. 1.3.1 Vehicle data...

  • Page 6: Possible Outputs

    Manual VEK S4C 1.3.3 Classification in the case of loop fault Speed and length measurement and classification is not possible in the case of a defective loop. A dummy vehicle (class = Other, l = 40 dm, v = 0 km/h) is reported for every vehicle which crosses the second intact loop.

  • Page 7: Synchronisation

    Manual VEK S4C 1.6 Synchronisation To prevent mutual interference between induction loops of multiple detectors, the latter can be synchronized with each other using a connection in the front-side ribbon cable. All detectors connected via the synchronous line process the multiplexing sequence synchronously. Only loops which are active in the same time window can affect each other.

  • Page 8: Settings

    For long loop supply lines it is recommended to use band 2..4 for frequency setting. If automatic frequency setting is activated, the VEK S4C uses the device address to choose one of the frequency ranges above. Please check the real frequency, because it can differ from the nominal frequency.

  • Page 9: Classification

    Automatic calculation of this factor is also available. By setting ‘0’ for the amplitude factor the VEK S4C begins to evaluate the next 50 cars in the length range of 350...450 cm. If the evaluation process is finished the VEK S4C stores the new adjustment factor in the EEPROM.

  • Page 10: Output Modes

    Manual VEK S4C Vehicle counter • Each classification module has a 16-bit counter per vehicle class and travel direction which can be invoked via the RS485 interface. It must be noted that the counters roll over at 65535 (2 ) and restart from 0. It is not recommended to reset the counters otherwise vehicles can be lost at the time of the reset.

  • Page 11: Simulation Of Output Signals

    The VEK S4C is downwards compatible with the interface protocols defined for the VEK S3. The protocols based on the TLS defined in the VEK S3 are also supported. In these cases, one VEK S4C behaves like two separately addressable VEK S3 units. Mixed operation of VEK S3 and VEK S4C on a common bus is not recommended.

  • Page 12: Initial Start-Up

    Manual VEK S4C Initial Start-up 1. Installation – The 19” rack must be grounded and PE contact on the DIN connector must connected to Ground. 7.10 PE connection  2. Address – The detector address is set to 48 at the factory using the software address offset. All detectors which will be operated on a common interface must be set to different addresses before initial start-up.

  • Page 13: Display And Operation

    Manual VEK S4C Display and Operation 4.1 Display elements The front panel of the detector contains 4 green LEDs for indicating the respective loop state. LED behaviour in normal operation: Description Loop free Loop busy or direction pulse flashes slowly...

  • Page 14: Factory Settings

    Manual VEK S4C 4.3 Factory settings To restore the factory default parameters, proceed as follows: 1) Press button 6x briefly until shows on the LEDs. 2) Hold button down  After one second all LEDs flash rapidly. After two seconds the LEDs go out.

  • Page 15: Device Address

    Manual VEK S4C 4.4 Device address The device address results from the hardware device address set using the DIP switches or DIN connector and the software settable address offset. Device address = Hardware device address + Address offset For downward compatibility to traffic detector VEK S3 the step size for the hardware device address is 2.

  • Page 16: Dip Switches

    Manual VEK S4C 4.4.2 Addressing with DIP switch 0: Off 1: On Device address for Hardware DIP switch Adr.-Offset 48 device address DIN connector (factory setting) Only valid, if address pins  on DIN connector are not connected! “1 1 1 1”...
  • Page 17 120Ω Bus Low ..470Ω RS485 devices (e.g. VEK S4C) The shown resistors are switchable by the help of the DIP-switches DIP switch Description 470 Ω-Pull-up resistor on RS485 B+ 470 Ω-Pull down resistor on RS485 A- Bus termination 120 Ω...

  • Page 18: Synchronisation Display

    Manual VEK S4C 4.6 Synchronisation display Correct function of the synchronisation for multiple detectors is indicated by the scrolling effect of the LEDs in an 8 s rhythm. As the device address increases from left to right, the scrolling LEDs also run from left to right for all synchronised detectors.

  • Page 19: Mechanical Data

    Manual VEK S4C Mechanical data 5.1 Dimensions PCB: 19” plug-in board, 100 x 160 x 19 mm Total: 125 x 186 X 25 mm, Front panel 3HE / 5TE 5.2 Board elements FEIG ELECTRONIC GmbH 11/17...

  • Page 20: Technical Data

    Manual VEK S4C Technical data Supply voltage 12 .. 24 V DC ±20 % SELV, limited power sources according to EN 62368-1 Power consumption typ. 900 mW, max. 1,2 W Dimensions 3HE / 5TE, EURO card, 100 mm x 160 mm...

  • Page 21: Approval / Standards

    Manual VEK S4C Outputs Low-Side Switch Open Drain, short-circuit protected max. 45 V / 350 mA, Ron = > 4 Ω Opto coupler max. 45 V / 20 mA Connectors back side DIN 41612 connector, Type B, 64-pole front side...

  • Page 22: Connectors And Pin Assignment

    Manual VEK S4C Connectors and pin assignment 7.1 DIN connector Connector: DIN 41612 Type B Open drain 1 Opto coupler 1- Opto coupler 1+ Opto coupler Fault+ Loop 1a Loop 1b Opto coupler Fault+ Opto coupler 2- Open drain 2...

  • Page 23: 2X7-Pole Pin Idc Connector For Ribbon Cable

    Manual VEK S4C 7.2 2x7-pole pin IDC connector for ribbon cable Front view - 14   RS485 A 12 RS485 B   CAN Low 10 CAN High   Synchronisation     24 V 24 V ...

  • Page 24: Open Drain Outputs

    Alternatively you can connect the circuit board to ground via grounding the front panel, if the 0-ς resistor R1 is placed on the board. (see also 5.2, Board elements) Noise immunity of the VEK S4C cannot be guaranteed without a PE connection! 11/17...

  • Page 25: Accessories

    8.2 Service software The traffic detector can be parameterised using the S4Com service program. As the VEK S4C is downwards compatible and supports the interface protocols of the VEK S3, the S3ComWin service program can also be used.

  • Page 26: Safety Instructions And Warnings

    Manual VEK S4C Safety instructions and warnings • The device should only used for the applications described by the manufacturer. • Please keep this operation instruction always accessible and hand it over to every user. • Inadmissible modifications to the device, use of repair parts and supplementary equipment which are not sold or recommended by the manufacturer can cause burning, electric shock and injuries.

  • Page 27: Functions In 4-Channel Mode

    VEK S4C 10 Functions in 4-channel mode The VEK S4C detector can also be used for presence detection with flexible direction recognition due to its integrated 4-channel functions (4Ch). The parameters for use as a presence detector are explained in this chapter.

  • Page 28: Response Sensitivity (4Ch)

    1000 4.17% 7,85 % 2550 10.63 % lowest sensitivity 18,29 % Note: The response thresholds of the VEK S4C are different from the response threshold of the ∆ VEK M4D for the same sensitivity ( f/f). 11/17 FEIG ELECTRONIC GmbH...

  • Page 29: Hysteresis Drop (4Ch)

    Manual VEK S4C 10.3 Hysteresis drop (4Ch) In order to avoid an intermediate loss of the occupied signal for vehicles with a high undercarriage such as articulated buses, trams, trucks with trailers etc, it is possible to modify the switching hysteresis. An interruption-free detection of critical vehicles is then also possible for low sensitivity setting.

  • Page 30: Direction Recognition (4Ch)

    VEK S4C 10.5 Direction recognition (4Ch) In addition to the simple direction recognition present in the classification modules, the VEK S4C detector has two parameterisable logic modules for the direction-dependent recording of vehicles. Complex evalua- tion algorithms using double loops are integrated in the detector. The direction logic generates logical output signals which can be output via a hardware output or via an interface depending on the setting.
  • Page 31 Manual VEK S4C Direction logic Signal output Signal drop off Remark D1 - Continuous signal 1 left 1. loop Allocation 1. loop DB - Continuous signal Signal output in opposite direction takes place only both loops again if both loops were free before- left 2.
  • Page 32 Manual VEK S4C 10.5.1 Direction detection in various traffic situations Various traffic situations are shown in the following for loop 1 and 2. The evaluation of the direction signal is performed in the same manner in the reverse direction of travel as well for loop 3 and 4 or other loop combinations.
  • Page 33 Manual VEK S4C 10.5.1.2 Traffic line Ri1 Ri2 Imp Imp Imp Imp 10.5.1.3 Wrong-way driver 1 Ri1 Ri2 Imp Imp FEIG ELECTRONIC GmbH 11/17...
  • Page 34 Manual VEK S4C 10.5.1.4 Wrong-way driver 2 Ri1 Ri2 Imp Imp 10.5.1.5 Maneuverer 1 Ri1 Ri2 Imp Imp 11/17 FEIG ELECTRONIC GmbH...
  • Page 35 Manual VEK S4C 10.5.1.6 Manoeuverer 2 Ri1 Ri2 Imp Imp Imp Imp FEIG ELECTRONIC GmbH 11/17...
  • Page 36 Manual VEK S4C 10.5.1.7 Wrong-way driver in traffic line Ri1 Ri2 Imp Imp 10.5.1.8 Cross-traffic Ri1 Ri2 Imp Imp All logics except for PB in Direction 1 will result in incorrect counts in this traffic situation, since they count in instead of out.
  • Page 37 Manual VEK S4C 10.5.2 Direction logic „Parking Bay“ This direction logic is used for short entrances and exits. This logic suppresses compromising of the count by cross-traffic on Loop 1. This means it is non-critical whether Loop 1 is placed in the passing lane or in the manoeuvring area.

  • Page 38: Notes

    Manual VEK S4C 11 Notes 11/17 FEIG ELECTRONIC GmbH...
