- Page 1 ® INSTALLATION OBID i-scan ID ISC.ANT1300/680 Typ A English draft public (B) 2008-02-05 M71104-1e-ID-B.doc...
- Page 2 FEIG ELECTRONIC call explicit attention that devices which are subject of this document are not designed with components and testing methods for a level of reliability suitable for use in or in connection with surgical implants or as critical components in any life support systems whose failure to perform can reasonably be expected to cause significant injury to a human.
-
Page 3: Table Of Contents
4.3.2 Mounting of the components at the use of the Multiplexer ...........26 4.3.3 Configuration of a Gate antenna with Multiplexer............28 4.3.4 Setting the Multiplexer ....................29 4.3.5 DIP Switch Configuration ....................29 4.3.6 Jumper Configuration ....................30 FEIG ELECTRONIC GmbH Page 4 of 50 M71104-1e-ID-B.doc... - Page 4 Configuring the Reader in accordance with national RF regulations ....44 Technical Data Antenna ID ISC.ANT1300/680- Type A ..............46 Approval ........................49 5.2.1 Europe (CE) ........................49 5.2.2 USA (FCC) and Canada (IC)..................50 5.2.3 USA (UL) ........................51 FEIG ELECTRONIC GmbH Page 5 of 50 M71104-1e-ID-B.doc...
-
Page 5: Safety Instructions / Warning - Read Before Start-Up
Although this device doesn't exceed the valid limits for electromagnetic fields you should keep a minimum distance of 25 cm between the device and your cardiac pacemaker and not stay in an immediate proximity of the reader’s antennas for any length of time. FEIG ELECTRONIC GmbH Page 6 of 50 M71104-1e-ID-B.doc... -
Page 6: Performance Features Of The Id Isc.ant1300/680 Antennas
Antenna with dynamic tuning board ID ISC.DAT ID ISC.ANT-GIK Mounting material and cables for Reader, Power Splitter or Multiplexer ID ISC.ANT-GAK Acoustic alarm signal with mounting material Table 1: Available Antenna Types FEIG ELECTRONIC GmbH Page 7 of 50 M71104-1e-ID-B.doc... -
Page 7: Installation And Wiring
3.1 Dimensions of antenna The outside dimensions of the antenna are shown in Fig. 1 Fig. 1: Antenna outside dimensions All dimensions are in mm with general tolerance to ISO 2768 m (mean). FEIG ELECTRONIC GmbH Page 8 of 50 M71104-1e-ID-B.doc... -
Page 8: Mounting Preparation
2. After that the antenna has to be placed carefully again on the floor. Now you must remove the to fastening screws (hexagon socket width A/F2,5) of the antenna foot cover and remove it upwards. Fig. 3 Step 1 Step 2 Fig. 3: Opening the antenna foot FEIG ELECTRONIC GmbH Page 9 of 50 M71104-1e-ID-B.doc... -
Page 9: Installing The Antenna
The dimensions are shown in Fig. 4: Fig. 4: Floor plate dimensions All dimensions are in mm with general tolerance to ISO 2768 m (middle). FEIG ELECTRONIC GmbH Page 10 of 50 M71104-1e-ID-B.doc... - Page 10 Reader side. Alternatively the cables can be routed at the sides of the antenna bas like shown in Fig. 5 Fig. 5 Cable routing at the antenna sides FEIG ELECTRONIC GmbH Page 11 of 50 M71104-1e-ID-B.doc...
-
Page 11: Installing The Antenna Base And Antenna Body
The antenna will be screwed on the floor. Use the adjusting screws (Fig. 6) to align the antenna vertically. Adjusting screws (hexagon socket width A/F5) Fig. 6: Attaching and aligning the antenna FEIG ELECTRONIC GmbH Page 12 of 50 M71104-1e-ID-B.doc... -
Page 12: Typical Antenna Configuration (Gate Antenna With Two Antennas)
Note that the entire capture area of the antenna is larger than the three-dimensional area shown in the drawing. This means there are tag orientations in which the tag can be detected outside the capture area. FEIG ELECTRONIC GmbH Page 13 of 50 M71104-1e-ID-B.doc... - Page 13 Antenna Type A With reader and With reader and power splitter multiplexer ≤ 90 cm ≤ 95 cm Gate distance GD Number of tags at traverse speed 1 m/s Read serial number Read data FEIG ELECTRONIC GmbH Page 14 of 50 M71104-1e-ID-B.doc...
-
Page 14: Configuration And Setup Using Antenna Type -A With Power Splitter
Microsoft Windows . The service software is included on ® the OBID i-scan CD obtained from FEIG ELECTRONIC GmbH or can be downloaded on the Download Area of the Homepage www.feig.de. FEIG ELECTRONIC GmbH Page 15 of 50 M71104-1e-ID-B.doc... -
Page 15: Contents Of The Gate- Integration- Kit Id Isc.ant.gik
Hexagon spacer bolt M3x6 / Mounting PS or Multiplexer into the antenna foot Screw M3x6 / Mounting PS or Multiplexer into the antenna foot Screw M4x8 / Mounting Reader into the antenna foot FEIG ELECTRONIC GmbH Page 16 of 50 M71104-1e-ID-B.doc... -
Page 16: Mounting Of The Components At The Use Of The Power Splitter
1 piece of cable tie 2,5x105mm Pos.6 Brown Red wire to Com and Brown wire to NO of X9 Reader, Red wire to 2 and Black wire to 5 of terminal block FEIG ELECTRONIC GmbH Page 17 of 50 M71104-1e-ID-B.doc... - Page 17 Wind up the rest of the cable to loops and tied it together with 2 pieces of cable tie 4,8x280mm Pos.5 and place it in the antenna foot. FEIG ELECTRONIC GmbH Page 18 of 50 M71104-1e-ID-B.doc...
-
Page 18: Configuration Of A Gate Antenna With Power Splitter
(see Fig. 9). Tie all cables as far away from the antenna conductor as possible. The cables must never be allowed to contact the aluminum tube. Fig. 9: Tying the cables FEIG ELECTRONIC GmbH Page 19 of 50 M71104-1e-ID-B.doc... -
Page 19: Setting The Power Splitter
To check the settings of the antenna tuner the antenna foot has to be opened. For that you must remove the to fastening screws (hexagon socket width A/F2,5) of the antenna foot cover and remove it upwards. Fig. 10 Step 1 Step 2 Fig. 10: Opening of the antenna foot FEIG ELECTRONIC GmbH Page 20 of 50 M71104-1e-ID-B.doc... - Page 20 Capacitor C1 JP 11,12,13,14 open Capacitor C2 JP 21,22,25,26 open JP 23,24 closed Verify these settings. More on setting the ID ISC.DAT antenna tuner can be found in the corresponding installation manual (M40401-xde-ID-B). FEIG ELECTRONIC GmbH Page 21 of 50 M71104-1e-ID-B.doc...
-
Page 21: Reader Configuration With Power Splitter
„NO-TS“ – 16 Timeslots • Note: National RF regulations may require different „AFI“ – Disabled settings. (see 4.7 Configuring the Reader in accordance with national RF regulations) Set by clicking on “Write” FEIG ELECTRONIC GmbH Page 22 of 50 M71104-1e-ID-B.doc... - Page 22 ® OBID i-scan Installation ID ISC.ANT1300/680-A Step Action Note CFG1: Interface and Mode To tune, activate “ISO-Host Mode” Set by clicking on “Write” FEIG ELECTRONIC GmbH Page 23 of 50 M71104-1e-ID-B.doc...
-
Page 23: Tuning The Gate Antenna With Power Splitter
After each tuning pass the current tuning status is displayed. After successful tuning both antennas for „Gate 1“ are shown in green. After successful tuning close the DATuningTool again. FEIG ELECTRONIC GmbH Page 24 of 50 M71104-1e-ID-B.doc... -
Page 24: Configuration And Setup Using Antennas Type -A With Multiplexer
Microsoft Windows . The service software is included on ® the OBID i-scan CD obtained from FEIG ELECTRONIC GmbH or can be downloaded at the Download Area of the Homepage www.feig.de. FEIG ELECTRONIC GmbH Page 25 of 50 M71104-1e-ID-B.doc... -
Page 25: Mounting Of The Components At The Use Of The Multiplexer
1 piece of cable tie 2,5x105mm Pos.6 Brown Red wire to Com and Brown wire to NO of X9 Reader, Red wire to 2 and Black wire to 5 of terminal block FEIG ELECTRONIC GmbH Page 26 of 50 M71104-1e-ID-B.doc... - Page 26 10cm with 4 turns before the reader. Wind up the rest of the cable to loops and tied it together with 2 pieces of cable tie 4,8x280mm Pos.5 and place it in the antenna foot. FEIG ELECTRONIC GmbH Page 27 of 50 M71104-1e-ID-B.doc...
-
Page 27: Configuration Of A Gate Antenna With Multiplexer
(see Fig. 13:Tying the cables). Tie all cables as far away from the antenna conductor as possible. The cables must never be allowed to contact the aluminum tube. Fig. 13:Tying the cables FEIG ELECTRONIC GmbH Page 28 of 50 M71104-1e-ID-B.doc... -
Page 28: Setting The Multiplexer
ID ISC.ANT.MUX Multiplexer can be found in the corresponding installation manual (M30201-xde-ID-B). Fig. 14: DIP-Switch and Jumper positions 4.3.5 DIP Switch Configuration The DIP switch should be configured as indicated in the following table: Table 5: DIP switch configuration DIP-switch S1 FEIG ELECTRONIC GmbH Page 29 of 50 M71104-1e-ID-B.doc... -
Page 29: Jumper Configuration
To check the settings of the antenna tuner the antenna foot has to be opened. For that you must remove the to fastening screws (hexagon socket width A/F2,5) of the antenna foot cover and remove it upwards. Fig. 10 Step 1 Step 2 Fig. 15: Opening of the antenna foot FEIG ELECTRONIC GmbH Page 30 of 50 M71104-1e-ID-B.doc... - Page 30 Capacitor C1 JP 11,12,13,14 open Capacitor C2 JP 21,22,25,26 open JP 23,24 closed Verify these settings. More on setting the ID ISC.DAT antenna tuner can be found in the corresponding installation manual (M40401-xde-ID-B). FEIG ELECTRONIC GmbH Page 31 of 50 M71104-1e-ID-B.doc...
-
Page 31: Reader Configuration With Multiplexer
„NO-TS“ – 1 Timeslot • „AFI“ – Disabled Note: National RF regulations may require different settings. (see 4.7 Configuring the Reader in accordance with national RF regulations) Set by clicking on “Write” FEIG ELECTRONIC GmbH Page 32 of 50 M71104-1e-ID-B.doc... - Page 32 • „Number of Input Channels“ – 1 Input (Single Mode) • „MUX-Valid Time“ – 100 x 5 ms • „Number of Output Channels“ => 2 Set by clicking on “Write” FEIG ELECTRONIC GmbH Page 33 of 50 M71104-1e-ID-B.doc...
-
Page 33: Tuning The Gate Antenna With Multiplexer
After successful tuning both antennas are shown in green. If this does not succeed on the first try, start the process over again by clicking on „Start Tuning“ After successful tuning, close the DATuningTool again. FEIG ELECTRONIC GmbH Page 34 of 50 M71104-1e-ID-B.doc... -
Page 34: Testing The Gate Antenna
Are there devices nearby which may emit noise interference (larger machines or wireless devices)? • Are there interference from the mains? To determine which devices may be disturbing the gate, briefly disconnect them from the mains. FEIG ELECTRONIC GmbH Page 35 of 50 M71104-1e-ID-B.doc... -
Page 35: Reading A Serial Number
In this test the capture area of the gate antenna described in 4.1 Project Notes is checked. For other tags or other configurations the indicated ranges and read areas may differ accordingly. Fig. 17: Performance Test of the gate antenna FEIG ELECTRONIC GmbH Page 36 of 50 M71104-1e-ID-B.doc... - Page 36 Tag too insensitive, detuned or defective • Reader improperly configured (transmitting power, transponder type, modulation, transponder parameters, etc.). • A cable is defective or has a poor contact. • Reader, Power Splitter or antenna defective. FEIG ELECTRONIC GmbH Page 37 of 50 M71104-1e-ID-B.doc...
-
Page 37: Connecting And Setting The Alarm Kit (Optional)
The relay outputs are intended only for switching resistive loads. If an inductive load is used, the relay contacts must be protected by an external protection circuit. Reversing the polarity or overloading the outputs will destroy them. See also Installation Manual ID ISC.LRM2000-A/B FEIG ELECTRONIC GmbH Page 38 of 50 M71104-1e-ID-B.doc... -
Page 38: Reader Setting For Indicators
„REL-TIME“ 10 x 100ms Set by clicking on “Write” CFG9: Input/Output ΙΙ Assign Relay 1 to antenna 1+2 Set by clicking on “Write” CFG4: Transponder Parameter ISO 15693 Mode „AFI“ Enabled FEIG ELECTRONIC GmbH Page 39 of 50 M71104-1e-ID-B.doc... - Page 39 ® OBID i-scan Installation ID ISC.ANT1300/680-A ISO 15693 Mode Enter desired value in „AFI“ field. Set by clicking on “Write” FEIG ELECTRONIC GmbH Page 40 of 50 M71104-1e-ID-B.doc...
-
Page 40: Programming A Transponder With The Afi Byte
Write down the serial number of the Transponder Select „[0x27] Write AFI“ ADR: 1: addressed Serial Number: Select Transponder AFI: Desired AFI Number (not equal to 00) Read UID by clicking on „Send“ FEIG ELECTRONIC GmbH Page 41 of 50 M71104-1e-ID-B.doc... - Page 41 ® OBID i-scan Installation ID ISC.ANT1300/680-A To verify, read AFI byte by selecting [0x2B] Get System Information FEIG ELECTRONIC GmbH Page 42 of 50 M71104-1e-ID-B.doc...
-
Page 42: Activating Buffered Read Mode
Set by clicking on “Write” CFG12: Read Mode-Filter VALID-TIME e.g. 55 x 100 ms Set by clicking on “Write” CFG1: Interface and Mode Select „Buffered Read Mode“. Set by clicking on “Write” FEIG ELECTRONIC GmbH Page 43 of 50 M71104-1e-ID-B.doc... -
Page 43: Configuring The Reader In Accordance With National Rf Regulations
When placing the antennas in service, the systems integrator must ensure that the prescribed mounting instructions are followed, the necessary Reader settings are made and permissible limits according to the national regulations are not exceeded. FEIG ELECTRONIC GmbH Page 44 of 50 M71104-1e-ID-B.doc... - Page 44 CFG 4 / ISO-MODE / FAST Timeslots - CFG 4 / ISO-MODE 1 or 16 Timeslots / NO-TS Complete Timeslot length at Inverntory Command Option – „NO TAG“ CFG 4 / ISO-CMD-OPTION / BREAK FEIG ELECTRONIC GmbH Page 45 of 50 M71104-1e-ID-B.doc...
-
Page 45: Technical Data
• Operating Frequency 13,56 MHz • Transmit Power 2W – 12 W (250 mW Step - Software) • Modulation 10% - 30% and 100% (Software configurable) • Maximum transmitting power per antenna FEIG ELECTRONIC GmbH Page 46 of 50 M71104-1e-ID-B.doc... - Page 46 120 cm** – One tag orientation approx. 95 cm*** – All tag orientations • Antenna connection 1 x SMA plug (50 Ω) • Antenna connector cable RG58, 50 Ω, approx. 2 m long FEIG ELECTRONIC GmbH Page 47 of 50 M71104-1e-ID-B.doc...
- Page 47 =80 mA/m rms, transmitting power 8 W, aligned in all 3 dimensions for horizontal movement through the antenna. The detection performance also depending of the strength of the Transponder answer signal ! FEIG ELECTRONIC GmbH Page 48 of 50 M71104-1e-ID-B.doc...
-
Page 48: Approval
Equipment Classification according to ETSI EN 300 330 and ETSI EN 301 489: Class 2 The technical data of the ID ISC.LRM2000 Reader built into the ID ISC.ANT1300/680-A an- tenna can be found in the Installation Manual which is included with the device. FEIG ELECTRONIC GmbH Page 49 of 50 M71104-1e-ID-B.doc... -
Page 49: Usa (Fcc) And Canada (Ic)
003 du Canada. Further information and technical data of the ID ISC.LRM2000 Reader built into the ID ISC.ANT1300/680-A antenna can be found in the Installation Manual which is included with the device. FEIG ELECTRONIC GmbH Page 50 of 50 M71104-1e-ID-B.doc... -
Page 50: Usa (Ul)
® OBID i-scan Installation ID ISC.ANT1300/680-A 5.2.3 USA (UL) In preparation ! The following picture indicates the label position: FEIG ELECTRONIC GmbH Page 51 of 50 M71104-1e-ID-B.doc...
