- Page 1 PG6505-M0 rev 09/07 Gas Engine Pumps Instruction Manual MODELS: PG5505 & PG6505 SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153 Tel: 888-332-6419 Fax: 816-891-6599 E-mail: sales@bvahydraulics.com Website: www.bvahydraulics.com This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
-
Page 2: Product Description
PRODUCT DESCRIPTION BVA Hydraulics Gas Engine Pump is engineered to meet most industrial standards for Performance and Safety. These pumps provide hydraulic power when electricity and air power are not available. The pumps supply compressed hydraulic fluid to compatible applications i.e. - Page 3 (not shown, on reservoir) Control Valve Lever Hydraulic Oil Reservoir Oil Output Ports 3/8"-18NPTF Drain Plug Carry Handle Figure 1 - Model PG5505 Components Oil Dipstick Cap Gas Engine Fuel Cap Engine Starter Grip Frame Control Valve Control Valve Lever...
- Page 4 This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. There are hazards associated with the use of this equipment which can only be avoided by reading, DANGER understanding and following all the printed materials provided by the manufacturer of the gasoline engine which drives this hydraulic pump.
-
Page 5: Before Use
BEFORE USE 1. Most malfunctions in new equipment are the result of improper operation and/or improper set-up assembly. 2. Visually inspect all components for shipping damage. Do not use if any damage is found. Note: Gas Pump is shipped without hydraulic oil. Add oil before operating. 3. -
Page 6: Operation
Note: Control valve on this pump is 4-way, 3-position valve type, for use with double-acting cylinders. If your application requires a 3-way setting for single-acting cylinder as shown in figure 3(b), it can be changed by an authorized BVA Service Center. If you have any doubt, please contact BVA Technical Service 888-332-6419. -
Page 7: Maintenance
5. Wipe up any spilled fluid and reinstall the oil cap. Note: Never use brake fluid, transmission fluid, turbine oil, motor oil, alcohol, glycerin etc. Use of other than BVA Hydraulic oil, Mobil DTE 15M or equivalent, will void warranty and damage the pump, hose, and application. -
Page 8: Troubleshooting Guide
TROUBLESHOOTING GUIDE The following information is intended as an aid in determining if problem exists. Pumps should be repaired only by authorized BVA Service Center. For repair service, contact service center in your area. Symptom Possible Causes Corrective Action Application does not extend, move or •... -
Page 9: Limited Lifetime Warranty
• Damaged components, including but not limited to bent rams, dented or crushed cylinder walls, broken welds or couplers as well as worn out seals, o-rings and springs are the result of misuse and not covered by warranty and BVA Hydraulics will not provide any warranty credit for such damaged components. - Page 10 Gas Engine Pump Service Parts MODEL: PG5505 (Honda Engine) SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153 Tel: 888-332-6419 Fax: 816-891-6599 E-mail: sales@bvahydraulics.com Website: www.bvahydraulics.com Note: Not all components of the pump are replacement items, but are illustrated as a...
- Page 11 Gas Engine Pump Service Parts MODEL: PG6505 (Briggs & Stratton Engine) SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153 Tel: 888-332-6419 Fax: 816-891-6599 E-mail: sales@bvahydraulics.com Website: www.bvahydraulics.com Note: Not all components of the pump are replacement items, but are illustrated as a PG6505-M0 rev 09/07 convenient reference of location and position in the assembly sequence.
- Page 12 SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153 Tel: 888-332-6419 E-mail: sales@bvahydraulics.com...
