Air Hydraulic Pump
Instruction Manual
MODEL: PA7550 & PA7550M
SFA Companies
10939 N. Pomona Ave. Kansas City, MO 64153
Tel: 888-332-6419
*
Fax: 816-448-2142
E-mail: sales@bvahydraulics.com
Website: www.bvahydraulics.com
Maximum Operating Pressure 10,000 PSI
PA7550
PA7550M
!
This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
Obey all safety messages that follow this symbol to avoid possible injury or death.
Printed in Taiwan
Drawn By: 陳神佑 Date: 2017.01.13 File name: A6705_1701OUT
Advertisement
Table of Contents
Related Manuals for BVA PA7550
Summary of Contents for BVA PA7550
- Page 1 PA7550-M0_092017 Air Hydraulic Pump Instruction Manual MODEL: PA7550 & PA7550M SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153 Tel: 888-332-6419 Fax: 816-448-2142 E-mail: sales@bvahydraulics.com Website: www.bvahydraulics.com Maximum Operating Pressure 10,000 PSI 觀圖 PA7550 PA7550M This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
-
Page 2: Safety And General Information
SAFETY AND GENERAL INFORMATION PRODUCT DESCRIPTION Save these instructions. For your safety, read and understand BVA Hydraulics Air Hydraulic Pump is engineered to meet the information contained within. The owner and operator shall most industrial standards for Performance and Safety. It is have an understanding of this product and safe operating an air hydraulic pump with 4-way valve. - Page 3 WARNING • Study, understand, and follow all • Use only approved accessories and approved hydraulic instructions provided with and on this fluid. device before use. • Never attach ANY component not authorized by • No alteration shall be made to this manufacturer.
-
Page 4: Before Use
Pressure may be monitored by means of monitored by means of a load cell and digital indicator. optional manifolds and gauges (contact BVA Hydraulics). Correct application position can only be determined by the Load may be monitored by means of a load cells and operator of the equipment. -
Page 5: Maintenance
5. Shield pump with a protective cover. TROUBLESHOOTING GUIDE The following information is intended as an aid in determining if problem exists. Pumps should be repaired only by authorized BVA Service Center. For repair service, contact service center in your area. Symptom Possible Causes Corrective Action •... - Page 6 Air Hydraulic Pump Service Parts MODEL: PA7550 SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153 Tel: 888-332-6419 Fax: 816-448-2142 E-mail: sales@bvahydraulics.com Website: www.bvahydraulics.com Model No. A5727 Checked By: Approved By: Drawn By: 陳神佑 File name: A5727_1701EXP Date: 2017.01.13...
- Page 7 Air Hydraulic Pump Service Parts MODEL: PA7550 SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153 Tel: 888-332-6419 Fax: 816-448-2142 E-mail: sales@bvahydraulics.com Website: www.bvahydraulics.com Part No. Description Qty. A57-4-6003-100 Foot Pedal Assy. A57-6-2003-102 Foot Pedal Axle 677-5-0070-101 E-clip 649-1-0050-055...
- Page 8 Air Hydraulic Pump Service Parts MODEL: PA7550M SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153 Tel: 888-332-6419 Fax: 816-448-2142 E-mail: sales@bvahydraulics.com Website: www.bvahydraulics.com Model No. A6705 Checked By: Approved By: Drawn By: 陳神佑 File name: A6705_1701EXP Date: 2017.01.13...
- Page 9 Air Hydraulic Pump Service Parts MODEL: PA7550M SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153 Tel: 888-332-6419 Fax: 816-448-2142 E-mail: sales@bvahydraulics.com Website: www.bvahydraulics.com Part No. Description Qty. 649-1-0050-101 Bolt A67-3-1014-102 Control Valve Assy., Refer to Page #11 D05-6-1001-106 Nut A67-6-1011-104 Handle A57-4-4002-108 Oil Outlet Valve Assy.
- Page 10 SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153 Tel: 888-332-6419 Fax: 816-448-2142 E-mail: sales@bvahydraulics.com Website: www.bvahydraulics.com Part No. for Model Description Qty. A57-3-1027-103 A67-4-0005-102 (PA7550) (PA7550M) Valve Base Washer A57-6-1003-107 Cylinder A57-6-1002-105 Cylinder Cover 649-1-0060-122 Hex Bolt A17-4-2100-500 Air Piston Assy.
- Page 11 Air Hydraulic Pump Service Parts MODEL: A67-3-1014-102 SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153 Tel: 888-332-6419 Fax: 816-448-2142 Model No. A67-3-1014-102 E-mail: sales@bvahydraulics.com Website: www.bvahydraulics.com Part No. Description Qty. E05-6-1008-109 Handle A67-6-1012-106 Operation Bar 641-1-0098-103 Screw 649-1-0080-003 Screw 601-4-0030-095 Spring Pin...
-
Page 12: Limited Lifetime Warranty
• Damaged components, including but not limited to bent rams, dented or crushed cylinder walls, broken welds or couplers as well as worn out seals, o-rings and springs are the result of misuse and not covered by warranty and BVA Hydraulics will not provide any warranty credit for such damaged components.
