10.
Install the Heater Box Assemblies.
Place the heater boxes onto the electrical and thermocouple receptacles located behind
each oil pot. Figures 8 & 9.
The heater plug and thermocouple plug will connect to their respective sockets on the
underside of the heater box and deck of the cabinet. Figures 8 & 9.
The heater boxes are interchangeable and will fit on either side.
Set the splash guard on the heater boxes so that it is suspended between them. Figure 13.
Figure 8
11.
Add commercial grade frying oil.
Ensure the drain valves (located by opening the lower cabinet doors) are closed. Figure 7.
Add oil to the oil pot. Fill to the lower fill line stamped on the exterior of pot. Figure 10.
It is easier and safer to add cool oil to the oil pot than it is to remove hot oil.
When heated, the oil will expand.
Over filling will result in excessive splashing. Under filling will result in under cooked food
or poor and erratic temperature readings. Extreme low oil levels could cause smoking.
Older or degraded oil has a reduced flash & smoke point.
Follow the oil manufacturers recommendations for oil use.
NEVER operate the AutoFry with low or no oil!
MTI-40C OM 04/17 Rev C
AutoFry
MTI-40C Operator's Manual
9
63-0008C
Figure 9
Figure 10
