DOREL ASIA
ACCENT CHAIR
Model No:
DA487-G (GREY)
DA487-RE (RED)
UPC CODE:
0-65857-16562-3 (GREY)
0-65857-16563-0 (RED)
NOTE:
THIS INSTRUCTION BOOKLET
CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ AND
KEEP FOR FUTURE REFERENCE.
Lot number:
(TAKEN FROM CARTON)
___________________
Date of purchase:
_______ / _______ / _______
DO NOT RETURN PRODUCT TO THE STORE.
If a part is missing or damaged, contact our customer service
department. We will replace the part FREE of charge.
NEED HELP!
Tel #: 1-800-295-1980
CALL US FOR ASSISTANCE
E-Mail: das@dorel.com
1-800-295-1980
Fax #: 514-353-7819
DO NOT RETURN PRODUC
E-MAIL:DAS@DOREL.COM
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Dorel Asia DA487-RE
Summary of Contents for Dorel Asia DA487-RE
- Page 1 DOREL ASIA ACCENT CHAIR Model No: DA487-G (GREY) DA487-RE (RED) UPC CODE: 0-65857-16562-3 (GREY) 0-65857-16563-0 (RED) NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Lot number: (TAKEN FROM CARTON) ___________________ Date of purchase: _______ / _______ / _______ DO NOT RETURN PRODUCT TO THE STORE.
- Page 2 Check bolts/screws periodically and tighten them if necessary. LIMITED WARRANTY Dorel Asia warrants its product to be free from defects in material and workmanship and agrees to remedy any such defect. This warranty covers 1 year from the date of original purchase.
- Page 3 ACCENT CHAIR DA487-G / DA487-RE HARDWARE LIST Ø5/16" X 50mm Ø5/16" X 45mm HEX SOCKET HEAD BOLT HEX SOCKET HEAD BOLT 1 PC 8 PCS Ø22 X 1.5mm Ø12.5 X 1.0mm Ø5 X 65mm FLAT WASHER SPRING WASHER ALLEN KEY...
- Page 4 ACCENT CHAIR DA487-G / DA487-RE STEP 1 Attach seat cushion (B) to backrest (A) with flat washers (3), spring washers (4), hex socket head bolts (1) and (2). Use Allen Key (5) to tighten the bolts. NOTE: Do not fully tighten bolts.
- Page 5 ACCENT CHAIR DA487-G / DA487-RE STEP 2 Attach front legs (C) to the seat cushion (B) with flat washers (3), spring washers (4) and hex socket head bolts (1). Use Allen Key (5) to tighten the bolts. Tighten all bolts.
- Page 6 ACCENT CHAIR DA487-G / DA487-RE CAUTION: This unit is intended for use only with the products and/or maximum weights indicated. Use with other products and/or products heavier than the maximum weights indicated may result in instability or cause possible injury.
- Page 7 MODEL #: DA487-G / DA487-RE Customer Service PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE PLEASE CONTACT CUSTOMER SERVICE REPRESENTATIVES AT THE FOLLOWING NUMBERS SHOULD THERE BE ANY MISSING OR DEFECTIVE PART(S). Customer Service Phone Number 1-800-295-1980 Email: das@dorel.com...
