DOREL ASIA
TODDLER BED
DA7750
DA7750W
0-65857-17411-3
0-65857-17601-8
THIS INSTRUCTION BOOKLET
CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE
DATE OF PURCHASE:
______ / ______ / ______
DO NOT RETURN PRODUCT TO THE STORE.
If a part is missing or damaged, Contact our
customer service department. We will
replace the part FREE of charge.
MODEL NO:
ESPRESSO
WHITE
UPC CODE:
ESPRESSO
WHITE
READ AND KEEP FOR
FUTURE REFERENCE.
LOT NUMBER:
(TAKEN FROM CARTON)
Tel # : 1-800-295-1980
E-Mail: das@dorel.com
Fax #: 514-353-7819
NOTE:
Advertisement
Table of Contents
Related Manuals for Dorel Asia Baby Relax DA7750
Summary of Contents for Dorel Asia Baby Relax DA7750
- Page 1 DOREL ASIA MODEL NO: DA7750 ESPRESSO DA7750W WHITE TODDLER BED UPC CODE: 0-65857-17411-3 ESPRESSO 0-65857-17601-8 WHITE NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. LOT NUMBER: (TAKEN FROM CARTON) DATE OF PURCHASE: ______ / ______ / ______ DO NOT RETURN PRODUCT TO THE STORE.
- Page 2 CUSTOMER SERVICE If you are missing parts or have any questions about this product, contact our customer service representative first! CALL 1-800-295-1980 You can also order parts by writing to the address listed below. Please include the product model number, color and a detailed description of the part. Customer Service Department No.
- Page 3 NOTES * Ensure all parts and components are present before beginning assembly. * Phillips head screwdriver is not included. * Assembly will require 2 people. * Estimated assembly time: 45 minutes. * DO NOT use power tools. * Caution: Adult assembly required. * DO NOT lift bed from side rails when moving.
- Page 4 TODDLER BED DA7750/DA7750W HARDWARE LIST 1/4" x 2-3/4" 1/4" x 1-3/4" BOLT BOLT 20 PCS 2 PCS 1/4" x 1/2" BARREL NUT ALLEN KEY 10 PCS 1 PC 10mm x 40mm 8mm x 30mm WOOD DOWEL WOOD DOWEL 12 PCS 20 PCS...
- Page 5 TODDLER BED DA7750/DA7750W PARTS LIST HEADBOARD POST TOP PANEL MIDDLE PANEL 2 PCS 1 PC 1 PC BOTTOM PANEL FOOTBOARD POST FOOTBOARD PANEL 1 PC 2 PCS 1 PC LEFT SIDE RAIL RIGHT SIDE RAIL GUARDRAIL 1 PC 1 PC 2 PCS CENTER SUPPORT SLAT WIDE SUPPORT SLAT...
- Page 6 TODDLER BED DA7750/DA7750W STEP 1 Insert the wood dowel (5) into top panel (B), middle panel (C) and bottom panel (D). Attach panels (B, C & D) to the headboard posts (A) as shown below using bolt (1) and Allen key (4). NOTE: Do not fully tighten the bolts.
- Page 7 TODDLER BED DA7750/DA7750W STEP 2 Insert the wood dowels (5) to the footboard panel (F). Attach footboard panel (F) to the footboard posts (E) using bolt (1) and Allen key (4) as shown below.
- Page 8 TODDLER BED DA7750/DA7750W STEP 3 Insert wood dowels (6) into both ends of narrow support slats (L) and wide support slats (K) as shown. Insert barrel nut (3) into the hole on center support slat (J). Ensure the barrel nut (3) is flush with center support slat (J).
- Page 9 TODDLER BED DA7750/DA7750W STEP 4 Insert barrel nut (3) into the other end of center support slat (J). Ensure the barrel nut (3) is flush with center support slat (J). Attach the left side rail (G) to slats (K, L & J). Secure center support slat (J) to left side rail (G) with bolts (1) and Allen key (4).
- Page 10 TODDLER BED DA7750/DA7750W STEP 5 Insert barrel nuts (3) into both ends of the left and right side rail (G & H). Attach the headboard and footboard to the left and right side rail (G & H) by inserting bolts (1) through the headboard posts (A) and footboard posts (E ).
- Page 11 TODDLER BED DA7750/DA7750W STEP 6 Attach guardrail (I) to headboard posts (A) with bolts (1). Secure the guardrail (I) to the left and right side rails (G & H) with bolts (2) as shown. Use Allen key (4) to tighten the bolts. NOTE: Fully tighten all bolts installed in previous steps.
- Page 12 TODDLER BED DA7750/DA7750W CAUTION: This unit is intended for use only with the products and/or maximum weights indicated. Use with other products and/or products heavier than the maximum weights indicated may result in instability or cause possible injury. NEVER use bed with children under 15 months or weighing more than 50 lbs (22.7kg)
- Page 13 MODEL #: DA7750/DA7750W Customer Service PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE PLEASE CONTACT CUSTOMER SERVICE REPRESENTATIVES AT THE FOLLOWING NUMBERS SHOULD THERE BE ANY MISSING OR DEFECTIVE PART(S). Customer Service Phone Number 1-800-295-1980 Email: das@dorel.com Customer Service Fax Number 514-353-7819 Request Date: Name: Shipping Address:...
