Basic Ejector SLP/SBP
Operating Instructions
Note
The Operating instructions were originally written in German. Store in a safe place for future reference. Subject
to technical changes without notice. No responsibility is taken for printing or other types of errors.
Published by
© J. Schmalz GmbH, 06/22
This document is protected by copyright. J. Schmalz GmbH retains the rights established thereby. Reproduction of
the contents, in full or in part, is only permitted within the limits of the legal provisions of copyright law. Any mod-
ifications to or abridgments of the document are prohibited without explicit written agreement from
J. Schmalz GmbH.
J. Schmalz GmbH · Johannes-Schmalz-Str. 1 · 72293 Glatten, Germany · T: +49 7443 2403-0
schmalz@schmalz.de
EN-US · 30.30.01.00021 · 02 · 06/22
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Schmalz SLP 05
Summary of Contents for Schmalz SLP 05
- Page 1 Any mod- ifications to or abridgments of the document are prohibited without explicit written agreement from J. Schmalz GmbH. J. Schmalz GmbH · Johannes-Schmalz-Str. 1 · 72293 Glatten, Germany · T: +49 7443 2403-0 schmalz@schmalz.de EN-US · 30.30.01.00021 · 02 · 06/22...
-
Page 2: Table Of Contents
Contents Contents 1 Important Information ........................... 3 Note on Using this Document ...................... 3 The technical documentation is part of the product ................ 3 Symbol.............................. 3 2 Fundamental Safety Instructions........................ 3 Intended Use............................ 3 Non-Intended Use .......................... 3 Personnel Qualification........................ 4 Warnings in This Document........................ 4 Residual Risks............................ -
Page 3: Important Information
ð Failure to follow the instructions in these Operating instructions may result in injuries! ð Schmalz is not liable for damage or malfunctions that result from failure to heed these instructions. If you still have questions after reading the technical documentation, contact Schmalz Service at: www.schmalz.com/services... -
Page 4: Personnel Qualification
• Use in medical applications • Evacuation of objects that are in danger of imploding 2.3 Personnel Qualification Unqualified personnel cannot recognize dangers and are therefore exposed to higher risks! The operating company must ensure the following points: • The personnel must be commissioned for the activities described in these operating instructions. •... -
Page 5: Modifications To The Product
4 Do not look into vacuum openings such as suction lines and hoses. 2.6 Modifications to the Product Schmalz assumes no liability for consequences of modifications over which it has no control: 1. The product must be operated only in its original condition as delivered. -
Page 6: Dimensions
4.3 Dimensions SLP... SBP...S... Hose connection SBP...G... Threaded connection Clip bar Type SLP 05/07... SBP 05/07...S... SBP 05/07...G... SBP 10/15...S... 13.5 SBP 10/15...G... 13.5 G1/8" G1/8" G1/8" SBP 20/25...S... SBP 20/25...G... G1/4" G3/8" G3/8" Type SLP 05/07... SBP 05/07...S... 18.2 12.5... -
Page 7: Transport And Storage
1. Compare the entire delivery with the supplied delivery notes to make sure nothing is missing. 2. Damage caused by defective packaging or occurring in transit must be reported immediately to the carrier and J. Schmalz GmbH. 6 Installation 6.1 Installation Instructions For safe installation, the following instructions must be observed: •... -
Page 8: Pneumatic Connection
Mounting the ejector on a base ü Ensure that the ejector is completely resting on the base during mounting and is fastened without distortion and tension. 4 Secure the ejector (1) to the base with at least 2 fastening screws (2) (M4, torque = 0.7 Nm) and the corresponding washers. - Page 9 6.3.1 Connecting the Compressed Air and Vacuum To correspond with the imprint (4), the compressed air connection P is marked with the number 1 on the ejec- tor. 4 Connect the compressed air hose. The max. tight- ening torque is 0.7 Nm. To correspond with the imprint (4), the vacuum con- nection V is marked with the number 2 on the ejector.
-
Page 10: Maintenance
7 Maintenance 7.1 Safety Instructions Maintenance work may only be carried out by qualified personnel. 4 Create atmospheric pressure in the ejector’s compressed air circuit before working on the system! WARNING Failure to follow the instructions in these Operating instructions may result in injuries! 4 Read the Operating instructions carefully and observe the contents.
