Summary of Contents for Hisense Babysense Connect
- Page 1 Babysense Connect Non-Contact Movement Monitor User Manual...
- Page 2 Do not put any additional baby or pet in the bed. Babysense Connect is intended for use with one infant and cannot be used for two infants in one bed. Babysense Connect cannot be used with co-sleepers that are attached to the parent's/caregiver's bed.
-
Page 3: Installation
It is strongly advised that parents and caregivers learn how to give first aid to babies. Babysense Connect is a home movement monitor for infants up to one year of age, and is not to be used with high-risk infants requiring constant medical supervision. - Page 4 Sensor pad installation: In a crib/bassinet, the 2 sensor pads need to be placed at equal distance from the sides, so that the sensor pads are placed individually on the 1st and 3rd quarter of the crib/bassinet (See illustration 2). PLEASE NOTE: The sensors should be placed with the marking "THIS SIDE UP"...
- Page 5 Pass the cords of the sensor pads through special openings in the holder (see illustration 4 and 5). Attach sensor pad connectors to the outlets marked "SENSOR" on the back of control unit (see illustration 6 and 7). PLEASE NOTE: Do not insert any cable into the blocked socket, marked "DO NOT USE" (see illustration 7) Should the design of the crib not allow proper installation with the control unit holder, please use the supplied hanging hook (see illustration 6).
- Page 6 Activated. To stabilize connectivity and allow continuous communication between the Babysense Connect and the app, please place the hub in the same room as the Babysense Connect and ensure it is within Wi-Fi range. Please install (see instructions below) and pair the hub as per app instructions.
-
Page 7: Testing Operation
Note: Ensure that the auditory alarm can be heard in all locations throughout the home or place of care and that the Babysense Connect Control Unit is hung with the LEDs facing out so that they are easily visible. Testing Operation Babysense Connect is a highly sensitive device, which monitors a baby's movements through the mattress during sleep. -
Page 8: Troubleshooting Guide
Check that alarm can be heard in all locations throughout the home or place of care. Please ensure that the Babysense Connect Control Unit is hung with the LEDs facing out so that they are easily visible. In case the alarm does not sound within 20 seconds refer to the “Troubleshooting Guide”... - Page 9 Incorrect testing used is incorrect. alarm to activate will not properly test the natural of the monitor by operation of the Babysense Connect. taking baby out • Please review the “Daily Performance Test” Section to the bed to test for properly test that your device is functioning correctly.
-
Page 10: Technical Specifications
The diameter size of the sensor pad is 216mm Hub power input is a Micro-USB with 5V and 2A Babysense Connect has a service life of 3 years from date of purchase Conditions of Operation & Storage Conditions of operation are as follows: Temperature: 0 °C to 40 °C... - Page 11 Batteries should be removed, and device stored in a dry shaded place when not in use. It is applicableto replace sensor pads two years after their first use. Use only Babysense Connect sensor pads. Imported by Hisense Ltd 27 Shaked Street Hevel Modi‘in...
