- Page 1 INFANT MOVEMENT MONITOR User Manual S PATENT o. 5271412 can me can me ndroid...
- Page 2 Do not put any additional baby or pet in the bed. Babysense Connect is intended for use with one infant and cannot be used for two infants in one bed. Babysense Connect cannot be used with co-sleepers that are attached to the parent's/caregiver's bed.
-
Page 3: Installation
Installation To insert the batteries, remove the battery cover by placing your thumb/finger in the opening recess and gently pulling away from the control unit (see illustration 7). Insert, in accordance with the markings, 4 new and identical Alkaline size AA 1.5 volt batteries and close cover. Note: Please dispose of used batteries in accordance with local waste regulations. - Page 4 When using a crib/bed equipped with spring base, place extra wooden board (plywood) under each sensor pad, as shown in illustration 3. The recommended size of the board is at least 17’’ x 11’’ and 1/2’’ thick. 5. Pass the cord(s) of the sensor pad(s) through special openings in the holder (see illustration 4). Pass the cords of the sensor pads through special openings in the holder (see illustration 4).
- Page 5 Should the design of the crib not allow proper installation with the control unit holder, please use the supplied hanging hook (see illustration 6). Hang the control unit from the bottom edge of the crib or affix the hook with a screw (not supplied) to the bottom edge of the crib and hang the control unit from the bottom edge of the crib.
- Page 6 Please scan appropriate QR code (see QR Codes below) for your cellular device. Pair the Babysense Connect Control Unit as per App instructions. You may also download the app by selecting “Babysense App” in the App Store Note: The Babysense Connect comes with BLE Activated. can me can me...
-
Page 7: Operation
Note: Ensure that the auditory alarm can be heard in all locations throughout the home or place of care and that the Babysense Connect Control Unit is hung with the LEDs facing out so that they are easily visible. Testing Operation Babysense Connect is a highly sensitive device, which monitors a baby's movements through the mattress during sleep. -
Page 8: Troubleshooting Guide
Incorrect testing used is incorrect. alarm to activate will not properly test the natural of the monitor by operation of the Babysense Connect. taking baby out • Please review the “Daily Performance Test” Section to the bed to test for properly test that your device is functioning correctly. - Page 9 Symptom Possible Cause Solution The alarm does • Environmental • Perform a test which will detect the source of the not go off within influences detected movement that the device detects. For example, 20 seconds when by the sensor pads, sources of wind such as: air conditioner, an open performing the such as wind, fan,...
-
Page 10: Technical Specifications
Alarm volume typically 85dB SPL at distance of one meter The diameter size of the sensor pad is 216mm Babysense Connect has a service life of 3 years from date of purchase Conditions of Operation & Storage Conditions of operation are as follows: Temperature: 0 °C to 40 °C... - Page 11 Limited 1 Year Warranty This product is warranted to be free from defects in material and workmanship for a period of (1) year from the date of purchase, except as noted below. Baby Monitor Direct LLC will repair or replace this product, at our option, at no cost.
