Save Gauges / Clear Gauges

The FIC gauge interface scans for connected gauges on every power cycle (gauge internal
address 32 through 48). The Data Pro provides the option of 'Save Gauges' which bypasses the
default scan-range and checks for gauges only at previously configured addresses. Saving gauge
addresses reduces the startup and scanning time so the gauge tabs display quickly in the event of the
Data Pro application restart. The 'Save Gauges' button changes to 'Clear Gauges' once the
application completes the execution of the task
before making any new gauge connections so the FIC scans the complete gauge address range from
32 through 48 to detect new gauge connections. The text 'Save Gauges' on the FIC status screen
indicates that gauge addresses are not saved and the FIC is in the correct state to detect new gauge
connections.
THE FIC STATUS WINDOW SHOULD DISPLAY 'SAVE GAUGES' BEFORE ADDING OR
Data Pro
Operation Manual
Figure 31 – FIC Firmware Update Status Window
(Figure
** CAUTION **
CHANGING GAUGES.
32). The user must click on 'Clear Gauges'
