WARNING:
Using power tools may result in overtourquing screws causing threads to strip.
We are not responsible for replacements on parts where powertools where used.
CARE & MAINTENANCE: To clean your product, use mild soap and water. For heavy soil build-ups use any non-abrasive household cleaners or ask your Sales Representative about
2
Sister Bay Furniture Cleaner.Please contact our Customer Service Department for assembly assistance, questions or replacement parts at (800) 505-7926 or email
support@sisterbayfurniture.com. Our Customer Service Department is available Monday-Friday 8:30 a.m. to 4:30 P.m. CST
HDPE
HARDWARE:
8x
8x
16x
0-3016
0-2980
0-3017
1x
R2 SQ Bit
7/16" Socket Head Wrench
(Not Included)
7/16" Wrench
(Not Included)
PARTS:
1x
28 Umbrella
Puck
1x
1x
28-3 Leg
28 Ring
Asm B
Laguna
Collection
36" Bar Table.
MODEL No: 28-3
4x
0-5222
#8x1.5"
4x
0-5224
#8x2.5"
8x
0-5285
1/4 -20x2.5"
1x
1x
28-3 Leg
28 Top
Asm A
Advertisement
Table of Contents
Related Manuals for Sister Bay Laguna 28-3
Summary of Contents for Sister Bay Laguna 28-3
- Page 1 CARE & MAINTENANCE: To clean your product, use mild soap and water. For heavy soil build-ups use any non-abrasive household cleaners or ask your Sales Representative about Sister Bay Furniture Cleaner.Please contact our Customer Service Department for assembly assistance, questions or replacement parts at (800) 505-7926 or email support@sisterbayfurniture.com.
- Page 2 Laguna Collection 36" Bar Table. MODEL No: 28-3 DETAIL A DETAIL B Put together Leg Asm A & Leg Asm B. Set 28 Ring into place, holes should line up with center of leg (Shown in Place Umbrella Puck on top of assembled Leg Assemblies. DETAIL B).
- Page 3 Laguna Collection 36" Bar Table. MODEL No: 28-3 DETAIL C Lay table Top on cardboard or other flat surface to avoid scratches on surface. Place leg assembly from step 2 onto table top frame, align leg slots with hole in frame. Insert [2x] bolts [0-5285] w/ Washers [0-3017] through frame and leg slots (DETAIL C).
- Page 4 Laguna Collection 36" Bar Table. MODEL No: 28-3 Final Step: Great job! Don't forget to admire your work over your shoulder as you walk away to get a beverage.
