ELECTROMAGNETIC IMMUNITY
IMMUNITY TEST COMPLIANCE LEVEL
Electrostatic ± 8kV contact
discharge (ESD) ± 2, 4, 8 and 15kV air
IEC 61000-4-2
Electrical fast ± 2 kV for power supply lines
transient / burst
IEC 61000-4-4
Surge IEC 61000-4-5 ± 1 kV differential mode
Voltage dips, short 0% .5 Periods
interruptions and 0% 1 Period
voltage variations 70% 25 Periods
on power supply 0% 5 sec
input lines IEC
61000-4-11
Power frequency 30A/m 50 and 60Hz
(50/60 Hz) magnetic
field IEC 61000-4-8
NOTE: U is the A/C. mains voltage prior to application of the test level.
T
ELECTROMAGNETIC IMMUNITY
IMMUNITY TEST COMPLIANCE LEVEL
Conducted RF 3 Vrms
IEC 61000-4-6 150 kHz to 80 MHz
6 V rms in ISM bands
Radiated RF 3 V/m
IEC 61000-4-3 80 MHz to 2.7 GHz
WWW.MAXTEC.COM • (800) 748-5355
The MaxO2 ME+p was also tested for radiated immunity to RF wireless communication equip-
ment at the test levels below.
ELECTROMAGNETIC
ENVIRONMENT - GUIDANCE
Floors should be wood,
concrete or ceramic tile.
If floors are covered with
synthetic material, the
relative humidity should
be at least 30 %.
Mains power quality should be
that of a typical commercial
or hospital environment.
Mains power quality should be
that of a typical commercial
or hospital environment.
Mains power quality should be
that of a typical commercial
or hospital environment.
If the user of the MaxO2
ME+p requires continued
operation during power mains
interruptions beyond that
provided by the battery, it is
recommended that the MaxO2
ME+p is powered from an
uninterruptible power supply.
Power frequency
magnetic fields should
be at levels characteristic
of a typical location in
a typical commercial or
hospital environment.
ELECTROMAGNETIC
ENVIRONMENT - GUIDANCE
The MaxO2 ME+p is suitable
for the electromagnetic
environment of typical
hospital settings.
15
Frequency (Hz) Modulation
385 Pulse, 18 Hz, 50% DC
450 FM, 1 kHz Sine, ±5 Hz Deviation
710, 745, 780 Pulse, 217 Hz, 50% DC
810, 870, 930 Pulse, 18 Hz, 50% DC
1720, 1845, 1970 Pulse, 217 Hz, 50% DC
2450
5240, 5500, 5785
Level V/m
27
28
9
28
28
28
9
