B. Desktop/Laptop Wi-Fi Setup
1. Turn on the IPS-M920.
2. Search for available Wi-Fi networks.
3. Select XPicoWiFi_XXXXXX to
connect. See Figure 14.
Note: XXXXXX indicates the last
six characters of the MAC/Serial #
located on the XPicoWifi device, on
a label near the antenna and on the
inside of the controller cover
(e.g. 00-80-A3-AB-01-C8).
4. After clicking Connect, enter
"xpicowifi" in lower case as the
network security password. Click
on Next button to complete the
connection. See Figure 15.
5. Once connected, open a
browser window and type
"192.168.0.1:8081" in the address
bar. Press the Enter key.
See Figure 16.
6. A dialog box will appear. Type
"admin" in lower case in the User
Name box and the full MAC/
Serial # without dashes (e.g.
0080A3AB01C8) in the Password
box. Click on Log In button.
See Figure 18.
7. The XPico WiFi main page will open.
Click on Quick Connect at the top
of the menu and select the WiFi
network to be used (e.g. H88d3).
See Figure 19.
Figure 14: XpicoWiFi Connection
Figure 15: Network Security Password
Figure 16: xPicoWiFi Web Address
Figure 17: xPicoWiFi Login Dialog Box
Figure 18: xPico WiFi Main Page
