M920 & M920W pH/Dual ORP Controller Owner's Manual
IV. IPS-M920 Wi-Fi Setup
A. Smart Phone Wi-Fi Setup
1. Turn on the IPS-M920.
2. Search for available Wi-Fi networks.
See Figure 7.
3. Select XPicoWiFi_XXXXXX to
connect.
Note: XXXXXX indicates the last
six characters of the MAC/Serial #
located on the XPicoWifi device, on
a label near the antenna and on the
inside of the controller cover (e.g.
00-80-A3-AB-01-C8).
4. After clicking Connect, enter
"xpicowifi" in lower case as the
network security password. Click
on Join button to complete the
connection. See Figure 8.
5. Once connected, open a
browser window and type
"192.168.0.1:8081" in the address
bar. Press the Enter key.
See Figure 9.
6. A dialog box will appear. Type
"admin" in lower case in the User
Name box and the full MAC/
Serial # without dashes (e.g.
0080A3AB01C8) in the Password
box. Click on Log In button.
See Figure 10.
Figure 7: Available WiFi networks
Figure 8: Network Security Password
Figure 9: xPicoWiFi Web Address
Figure 10: xPicoWiFi Login Dialog Box
28
