3. With the carriages in equal position from the
floor, route the equalizer cables as shown
below. ( See Fig. 9 & 10 )
4. After the equalizer cables have been routed.
adjust each cable so that they are equal
tension.
IMPORTANT NOTE:
The equalizer cables should be checked
weekly for equal tension. Failure to do this will
cause uneven lifting. The cables should
always be adjusted so that they are equal
tension when resting on the safety locks.
Fig. 9
Fig. 10
STEP TEN
( Installing The Hydraulic Lines. )
1. Install the hydraulic lines as shown below pay-
ing careful attention to keep the hoses clean and
free of debris. ( See Fig. 11 & 12 )
When routing the hydraulic hose through the
columns, make sure to route through the
retaining rings welded inside each column.
Make sure that the hose is clear of any moving
parts. It may be necessary to tie hose clear by
using nylon tie straps or wire. Failure to keep
hydraulic lines clear may result in hydraulic line
failure which may result in damage or personal
IMPORTANT NOTE:
When installing hydraulic fittings and hoses it
is not necessary to use Teflon tape or other
sealant. Teflon tape and other sealing
compounds can contaminate the system and
cause malfunctioning of lift.
harm.
Fig. 11
