Bend-Pak EXCEL Series Installation And Operation Manual

Surface mounted two-post lifts

Advertisement

Quick Links

INSTALLATION AND OPERATION MANUAL
SURFACE
MOUNTED
TWO-POST
LIFTS
SHIPPING DAMAGE CLAIMS
When this equipment is shipped, title passes to the purchas-
er upon receipt from the carrier. Consequently, claims for the
material damaged in shipment must be made by the pur-
chaser against the transportation company at the time ship-
ment is received.
Forward this manual to all operators.
Failure to operate this equipment as
directed may cause injury.
Keep this operation manual near the
machine at all times. Make sure that
ALL USERS read this manual .
BE SAFE
Your new lift was designed and built with safety in
mind. However, your overall safety can be increased
by proper training and thoughtful operation on the part
of the operator. DO NOT operate or repair this equip-
ment without reading this manual and the important
safety instructions shown inside.
Santa Paula, CA. 93060, USA
EXCEL
SERIES
1645 Lemonwood Dr.
Tel: 1-805-933-9970
Fax: 1-805-933-9160
