Bend-Pak HD-9ST Installation And Operation Manual

9,000- pound capacity commercial grade four-post lift

Advertisement

Quick Links

INSTALLATION AND OPERATION MANUAL
9,000- POUND CAPACITY
COMMERCIAL GRADE
FOUR-POST LIFT
SHIPPING DAMAGE CLAIMS
When this equipment is shipped, title passes to the
purchaser upon receipt from the carrier. Consequently,
claims for the material damaged in shipment must be made
by the purchaser against the transportation company at the
time shipment is received.
Forward this manual to all operators.
Failure to operate this equipment as
directed may cause injury.
Keep this operation manual near the
machine at all times. Make sure that
ALL USERS read this manual .
BE SAFE
Your new lift was designed and built with safety in
mind. However, your overall safety can be increased
by proper training and thoughtful operation on the part
of the operator. DO NOT operate or repair this
equipment without reading this manual and the
important safety instructions shown inside.
Santa Paula, CA. 93060, USA
Revised 6/15/04
Models:
HD-9ST
HD-9
1645 Lemonwood Dr.
Tel: 1-805-933-9970
Fax: 1-805-933-9160
