Betriebsanleitung Bandsäge
D
Operating Instructions Band Saw
ENG
Notice d'emploi Scie à ruban
F
Gebruiksaanwijzing Bandzaag
NL
BAS 600
Achtung!
Lesen Sie diese Anleitung vor der Installation und Inbetriebnahme aufmerksam durch.
D
Attention!
Carefully read through these instructions prior to installation and commissioning.
ENG
Attention!
Prière de lire attentivement la présente notice avant l'installation et la mise en service.
F
Attentie!
Lees deze instructies voor de installatie en ingebruikname aandachtig door.
NL
®
Advertisement
Table of Contents
Related Manuals for Elektra Beckum BAS 600
Summary of Contents for Elektra Beckum BAS 600
- Page 1 ® Betriebsanleitung Bandsäge Operating Instructions Band Saw Notice d'emploi Scie à ruban Gebruiksaanwijzing Bandzaag BAS 600 Achtung! Lesen Sie diese Anleitung vor der Installation und Inbetriebnahme aufmerksam durch. Attention! Carefully read through these instructions prior to installation and commissioning. Attention! Prière de lire attentivement la présente notice avant l'installation et la mise en service.
-
Page 2: Table Of Contents
Should such repair or replacement become necessary, it is This Band Saw model BAS 600 is designed for sawing recommended that only genuine Elektra Beckum wood. Sawing or cutting any other material is not replacement parts are used and that such repairs are permitted. -
Page 3: Safety Information
Residual risks of woodworking machines Even if all safety guards are used the machine is used according to its specified condition of use all relevant safety regulations are observed the following residual risks remain: - hearing damage by noise emission - risk of injury by hand contact with the uncovered Fig. -
Page 4: Rip Fence
Bolt rip fence carrier extrusion to the band saw table Table tilt backstop setting with the 4 knurled screws M 6x25. The band saw table tilts up to 45°. The table can be tilted after loosening the wing nut on the table trunnions Snap the narrow slotted table insert into the centre On the underside of the saw table is a backstop, which table opening. -
Page 5: Band Saw Setup
Fig. 14 Fig. 11 4.1 Blade Guiding The blade guide of the band saw model BAS 600 provides for an exact guiding of the saw blade. With narrow saw blades ensure that the blade guide guides the blade below the table properly both from the rear and the sides. -
Page 6: Blade Setting
4.3 Blade Speed Selection handwheel (A). Put on gloves (!), then take blade off the This band saw model BAS 600 can be operated at blade upper band saw wheel and pull it out of the blade guide speeds between 410 m/min and 1025 m/min. The most extrusion and the band saw frame. -
Page 7: Electrical Equipment
Any other application requires be protected by a 16A time-lag fuse or miniature circuit the consent of Elektra Beckum in writing. Please do not breaker, its conductor cross section should be at least hesiate to contact Elektra Beckum or our local 3 x 1.5 mm... -
Page 8: Wiring Diagrams
Conducter Color Coding = blue gnge = yellow/green = red = brown = black 10 Spare Parts List BAS 600 Item Description Stock-no. Item Description Stock-no. Gearwheel 138 104 5869 Edge protection, flexible 705 603 5812 Circlip 8x0.8... - Page 9 101 019 0300 131 Guide roller 211 Crank handle with cap screw 700 411 9562 7000 Capacitor BAS 600 WNB 37.5 µF/400V 805 001 1829 height adjustment Ø 25x6.5 148 540 8882 132 Plastic washer Ø 12.2x30x3.1 239 120 5186...
- Page 10 U.K. Supplement to Operating Instructions for Elektra Beckum Band Saw BAS 600 Please note the following supplementary information associated with this machine: U.K. Legislation and Codes of Practice When used industrially within the U.K. this machine falls under the scope of...
