3. See Figure 2-15. Connect opposite regula-
tor connecting hose end to generator at
mounted LP primary regulator with the
19mm wrench.
Figure 2-15. Connect Hose to Regulator
4. See 2-16. Turn LP tank valve ON
Figure
and check for leaks by spraying soapy
water to check connections. If bubbles
appear, become larger in size, or increase
in number, a leak exists.
NOTE: Always position cylinder so the con-
nection between the valve and regulator won't
cause sharp bends or kinks in hose.
Figure 2-16. Turn LP Tank Valve On
NOTE: If a leak exists, this must be corrected
before using generator. Contact your local
IASD for assistance.
NOTE: When transporting and storing, keep
cylinder secured in an upright position with
cylinder valve turned off and the outlet
plugged. Keep cylinders away from heat and
ventilated when in a vehicle.
