- Page 1 Professional Display Solutions S Line 37BDL3050S User Manual (English) www.philips.com/welcome...
-
Page 2: Table Of Contents
Table Of Contents 10. Cleaning and Troubleshooting ........37 10.1. Cleaning ..............37 10.2. Troubleshooting ..........38 Safety Instructions ............iii 11. Technical Specifications ..........39 Unpacking and Installation .........xi Warranty policy for Philips Professional Display 2.1. Unpacking ............xi Solutions .................41 2.2. Package Contents ..........xi 2.3. -
Page 3: Safety Instructions
When turning off the display by detaching the power cord, wait 6 seconds before re-attaching the power cord for normal operation. • Ensure the use of an approved power cord provided by Philips at all times. If your power cord is missing, please contact your local service center. •... - Page 4 37BDL3050S IMPORTANT: Always activate a moving screen saver program when you leave your display unattended. Always activate a periodic screen refresh application if the unit will display unchanging static content. Uninterrupted display of still or static images over an extended period may cause “burn in”, also known as “after-imaging” or “ghost imaging”, on your screen. This is a well-known phenomenon in LCD panel technology.
- Page 5 37BDL3050S interference. Federal Communications Commission (FCC) Notice (U.S. Only) NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 6 37BDL3050S Polish Center for Testing and Certification Notice The equipment should draw power from a socket with an attached protection circuit (a three-prong socket). All equipment that works together (computer, display, printer, and so on) should have the same power supply source. The phasing conductor of the room’s electrical installation should have a reserve short-circuit protection device in the form of a fuse with a nominal value no larger than 16 amperes (A).
- Page 7 37BDL3050S Information for U.K. only WARNING - THIS APPLIANCE MUST BE EARTHED. Important: This apparatus is supplied with an approved moulded 13 A plug. To change a fuse in this type of plug proceed as follows:+ 1. Remove fuse cover and fuse. 2.
- Page 8 37BDL3050S China RoHS 根据中国大陆《电器电子产品有害物质限制使用管理办法》，以下部分列出了本产品中可能包含的有害 物质的名称和含量。 有害物质 部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr (VI)) (PBB) (PBDE) 外壳 液晶显示屏 电路板组件* 电源适配器 电源线/连接线 遥控器 本表格依据SJ/T 11364 的规定编制。 *: 电路板组件包括印刷电路板及其构成的零部件，如电阻、电容、集成电路、连接器等。 O: 表示该有害物质在该部件所有均质材料中的含量均在 GB/T 26572规定的限量要求以下。 X: 表示该有害物质至少在该部件的某一均质材料中的含量超出GB/T 26572规定的限量要求。 上表中打 “X” 的部件， 应功能需要， 部分有害物质含量超出GB/T 26572规定的限量要求， 但符合欧盟 RoHS法规要求...
- Page 9 Please find out about the local regulations on how to dispose of your old display from your local Philips dealer. (For customers in Canada and U.S.A.) This product may contain lead and/or mercury.
- Page 10 For more information about E -waste please visit http://www.india.philips.com/about/sustainability/recycling/index.page and to know where you can drop off your waste equipment for recycling in India please contact on below given contact details.
-
Page 11: Unpacking And Installation
• HDMI cable and AAA Batteries • AC Switch Cover x1 • Wall mount Bolt x2 • Philips logo plate IR Sensor Cable Power Cord RS232 Crossover Cable RS232 Daisy Chain Cable Philips logo AC Switch Cover Wall Mount Bolt (x2) -
Page 12: Unpacking Notes
37BDL3050S 2.3. Unpacking Notes Before unpacking: • Please read and fully understand this document before installation. • Make sure no serious damages to the packaging. • Please do necessary inspection before taking out the display. • Installation should only be performed by professional technicians. •... - Page 13 37BDL3050S Step1: Open the box and take out the accessories. Step3: • Install the Wall Mount Bolt to the wall mount holes by using the hexagon socket. • Plug all input/output cables. • Install the wall mount brackets. (optional) Step2: Step4: Mounting the display to the wall.
-
Page 14: Installation Notes
37BDL3050S 2.4. Installation Notes • Only use the power cable provided with this product. If an extension cord is required, please consult your service agent. • The product should be installed on a flat surface, or the product may tip over. Leave a space between the rear of the product and the wall for proper ventilation. -
Page 15: Mounting In Portrait Orientation
37BDL3050S 2.7. Mounting in Portrait Orientation This display can be installed in portrait orientation. Rotate the display 90 degrees clockwise. The “ ” logo should be on the left side when facing the display. NOTE: The working hour in portrait mode is 24 hours per day. 90°... -
Page 16: Parts And Functions
37BDL3050S Parts and Functions 3.1. Control Panel [ ] button [MENU] button Press this button to turn the display On or turn the display to Return to the previous menu while the OSD menu is On. This standby mode. button can also be used to activate the OSD menu when the OSD menu is Off. -
Page 17: Input/Output Terminals
37BDL3050S Input/Output Terminals 3.2. RS232 RS232 IR-IN IR-OUT USB2.0 HDMI OUT HDMI IN AUDIO VGA IN RJ45 IN RJ45 OUT MICRO SD AUDIO IN IR IN / IR OUT AC IN IR signal input / output for the loop-through function. AC power input from the wall outlet. -
Page 18: Remote Control
37BDL3050S 3.3. Remote Control Show Information OSD. NAVIGATION buttons 3.3.1. General functions Root Menu: Go to the OSD of Smart picture. Main Menu: Move the selected item up to make adjustment. IR Daisy Chain Menu: Increase the controlled Group ID number. - Page 19 37BDL3050S 3.3.2. ID Remote Control Press the [ID] button and the red LED blinks twice. 1. Press [ID SET] button for more than 1 second to enter the Set remote control ID number when using several displays. ID Mode. The red LED lights up. Press the [ID SET] button again will exit the ID Mode.
- Page 20 3. When playing a video or music file, you can press button to pause playing. 4. All media files should be located in the folder of “philips”, under the root directory of the specified storage (internal/USB/SD Card). All sub-folders (video/photo/ music) are named by media types and shouldn’t be changed.
- Page 21 37BDL3050S ] BACK button Return to the previous page or exit from the previous function. ] MUTE button Mute or unmute the sound. The button is only controlled by Scalar. [ ] [ ] [ ] [ ] COLOR buttons [Number/ ID SET/ ENTER] button ID SET and ENTER...
- Page 22 37BDL3050S 3.3.4. Inserting the batteries in the remote control The remote control is powered by two 1.5 V AAA batteries. To install or replace batteries: 1. Press and then slide the cover to open it. 2. Insert batteries with the correct polarity (+) and (-). 3.
- Page 23 37BDL3050S 3.3.7. Using the remote sensor and power indicator 1. Push down the lens to have better remote control performance and make it easy to observe the power status. 2. Pull up the lens before mounting the display for video wall application. 3.
-
Page 24: Ac Switch Cover
37BDL3050S 3.4. AC Switch Cover • Use AC Switch Cover to cover the AC switch. • Fix the AC Switch Cover with the screw from accessory pack. -
Page 25: Connecting External Equipment
37BDL3050S Connecting External Equipment 4.1. Connecting External Equipment (Multimedia Player) 4.1.1. Using HDMI video input HDMI IN Multimedia Player [HDMI IN] HDMI Out 4.2. Connecting a PC 4.2.1. Using HDMI input HDMI IN [HDMI IN] HDMI Out 4.3. Connecting Multiple Displays in a Daisy-chain Configuration You can interconnect multiple displays to create a daisy-chain configuration for applications such as a menu board. -
Page 26: Ir Connection
37BDL3050S DISPLAY 1 DISPLAY 2 [RS-232C] [RS-232C IN] [RS-232C OUT] [RS-232C IN] 4.4. IR connection External IR Receiver DISPLAY 1 [IR IN] NOTE: This display’s remote control sensor will stop working if the [IR IN] is connected. 4.5. IR Pass-through Connection [IR OUT] Multimedia Player [IR IN]... -
Page 27: Wire-Connecting To Network
37BDL3050S 4.6. Wire-connecting to Network INTERNET ROUTER [RJ-45] [RJ-45] Network Settings: 1. Switch the router on and enable its DHCP setting. 2. Connect the router to this display with an Ethernet cable. 3. Press [ ] HOME button on the remote control, then select Setup 4. -
Page 28: Operation
• When you leave from Admin mode, the system will return to last source. Settings: go to settings app. Help: display the QR code to link to Philips support website. 1) Settings: 2) Help page: Display the QR code to link to Philips support website. -
Page 29: Setting Ui
37BDL3050S Setting UI On the available network list, select an AP (access point) on an existing wireless network. 6.1. Settings Enter PD settings by clicking “Settings” icon in Admin mode. Setting menu consists of the following items: Enter the required settings. (1). - Page 30 37BDL3050S Wi-Fi Preference By default, the system uses DHCP to join the network. Connection Information (When the options are grayed out, Settings -> Network & Internet -> Wi-Fi -> Wi-Fi Preference they are not editable). (1). IP Address (2). Gateway (3).
- Page 31 When it is set to “User” mode, the option “Choose Boot Animation” becomes available. When Logo is set to “User” mode, the default Philips logo will be replaced by user selected boot animation file. Click “Choose Boot Animation” and a pop-up menu appears 6.1.2.1.
- Page 32 The function of mailing out the “bootanimation.zip” has not been saved before by user. screenshot is consequently suspended. The screenshot- Default Philips logo appears during system boot up. related features will be restarted when the system enters active mode.
- Page 33 2. User cannot set port 5000 (SICP default port) and 2121 The screen images will be saved under the folder named (FTP server default port). “philips/screenshot” of the internal storage. SICP network port setting in “Settings -> Signage Display (6). Purge Screenshots ->...
- Page 34 37BDL3050S Manager Email Bind status: Specify the destination address to receive the e-mail. (1). If the device does not have appropriate network connection, a message “Network is disconnected” will appear. (2). If the device is equipped with network function, but is not connected to the remote control server, a message Test “Server is disconnected”...
- Page 35 Clear data under {storage}/philips/folder of the internal and external storage. SICP Network Port (1). All Clear the folder “Philips” from the internal storage, USB Settings -> Signage Display -> Network Application -> SICP and SD card. Network Port (2). Internal Storage Set up the default port of SICP and enable/disable the Clear the folder “Philips”...
- Page 36 CMS file will be saved to root directory of storage If the selected storage (internal storage, USB or SD card) does not contain Philips/folder, then the system will create it automatically. A list of all available storage (internal storage, SD card and...
- Page 37 37BDL3050S (1). Do not turn off the power or remove the power adapter until the update is complete. (2). Current system only supports full Android update. (3). The update file must be named as “update.zip” only. (4). The “update.zip” file must be stored in the root folder of your external storage.
- Page 38 37BDL3050S 6.1.3. Apps Display installed APKs information. 6.1.4. Display Change the font size of your display. 6.1.3.1. App info All installed Android APP are listed. User can manage each APP’s permission and other settings. 6.1.4.1. Font Size Drag the slide to adjust system font size. Default setting is “Largest”.
- Page 39 37BDL3050S 6.1.6.1. Keyboard & input 6.1.6.3. About Settings -> System -> Keyboard & input Settings -> System -> About User can change IME and keyboard settings. View the following information about the system. (1). Status (2). Legal information (3). Model (model name of this device) Virtual keyboard (4).
-
Page 40: Osd Menu
37BDL3050S OSD Menu 7.2. OSD Menu Overview An overview of the On-Screen Display (OSD) structure is 7.2.1. Picture menu shown below. You can use it as a reference for further adjustment of your display. 7.1. Navigating the OSD Menu 7.1.1. Navigating the OSD menu using the remote control Brightness 1. - Page 41 37BDL3050S Gamma selection Press + button to move screen to right. Select a display gamma. It refers to the brightness Press - button to move screen to left. performance curve of signal input. Choose from {Native} / NOTE: VGA input only. {2.2} / {2.4} / {s gamma} / {D-image}.
- Page 42 37BDL3050S Minimum Volume Note: Video source only. Adjust limitation for the minimum volume setting. RS232 routing Mute Select RS232 routing path Turn the mute function on/off. • {RS232} – RS232 is routed from 2.5 mm phone jack • {LAN->RS232} – RS232 is routed from RJ45 Audio Source Boot on source Select the audio input source.
- Page 43 • {On} – Default value. Both Philips logo and Android boot animation will be shown. • {User} – Static Philips logo will not be shown, only user- selected boot animation will be shown in Android settings. IR control Note: Logo will not be rotated even thought rotation setting is set.
- Page 44 37BDL3050S • Brightness: {Normal} – Adjust the overall image and Date and time background screen brightness (backlight) in Screen menu. {ACS} – Apply brightness values (backlight) Auto Sync which is adjusted by MIC tool. The default value before Set date adjustment is the same as brightness setting in Screen Set time menu.
- Page 45 37BDL3050S OSD Transparency Adjust OSD transparency. • {Off} - Transparency off. • {1-100} - Transparency level 1-100 Power Save Mode 1 [TCP off, WOL on, auto off] Mode 2 [TCP off, WOL on, auto on/off] Mode 3 [TCP on, WOL off, auto on/off] Mode 4 [TCP on, WOL off, no auto on/off] Power RCU Power...
-
Page 46: Input Mode
37BDL3050S Input Mode Timing support: Item Resolution H.Freq. (KHz) V.Freq. (Hz) 720×400 @ 70Hz DOS 31.469 70.087 640×480 @ 60Hz DMT 31.469 59.94 640×480 @ 67Hz MAC 66.667 640×480 @ 75Hz DMT 37.5 800×600 @ 60Hz DMT 37.879 60.317 832×624 @ 75Hz MAC 49.725 74.5 1024×768 @ 60Hz DMT... -
Page 47: Pixel Defect Policy
However, pixel or sub-pixel defects on the PDP/TFT panels used in Plasma- & LCD- displays are sometimes unavoidable. No manufacturer can guarantee that all panels will be free from pixel defects, but Philips guarantees that any Plasma- & LCD- displays with an unacceptable number of defects will be repaired during the warranty period in line with your local guarantee conditions. -
Page 48: Dark Dot Defects
Pixel Defect Tolerances In order to qualify for repair due to pixel defects during the warranty period, a PDP/TFT panel in a Philips Plasma / LCD- display must have pixel or sub-pixel defects exceeding the tolerances listed in the following table. -
Page 49: 10. Cleaning And Troubleshooting
37BDL3050S 10. Cleaning and Troubleshooting 10.1. Cleaning Caution When Using the Display • Do not bring your hands, face or objects close to the ventilation holes of the display. The top of the display is usually very hot due to the high temperature of exhaust air being released through the ventilation holes. Burns or personal injuries may occur if any body parts are brought too close. -
Page 50: 10.2. Troubleshooting
37BDL3050S 10.2. Troubleshooting Symptom Possible Cause Remedy No picture is displayed 1. The power cord is disconnected. 1. Plug in the power cord. 2. The main power switch on the back of 2. Make sure the power switch is the display is not switched on. switched on. -
Page 51: Technical Specifications
37BDL3050S Technical Specifications Display: Item Specifications Screen Size (Active Area) 904.32(H) x 254.34(V)/37.0 Inch Aspect Ratio 32:9 Number of pixels 1920 x 540 Pixels Pixel pitch 0.47 (H) x 0.47 (W) [mm] Displayable colors Normally Black Brightness (typical) 700 cd/m Contrast ratio (typical) 4000:1 Viewing angle... - Page 52 37BDL3050S General: Item Specifications Power Input 100 - 240V~, 50/60Hz Power Consumption (Max) 85 W Power Consumption (typ.) 70 W Power Consumption (Standby <0.5 W Mode & Off Mode) Dimensions [W x H x D] 928.5 mm x 282.3 mm x 48.7 mm Weight 7.76 Kg Gross Weight...
-
Page 53: Warranty Policy For Philips Professional Display Solutions
LIMITED WARRANTY In the unlikely event the product requires service, we will arrange for your Philips product to be serviced free-of-charge within the warranty period, provided that the product was used in accordance with the user manual (e.g. in the intended environment). - Page 54 Warranty period for PHILIPS signage display is listed as below, for areas not covered in this table, please follow their warranty statement. Standard warranty period for PHILIPS signage display is listed as below, for areas not covered in this table, please follow the local warranty statement.
-
