Manual
Variable speed
jig saw
CALA-A3
CAUTION
Read this manual thoroughly
before using the tool.
0.7 Hp
Power
Applies for:
Code
Model
15420
CALA-A3
3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRO CALA-A3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Truper PRO CALA-A3

  • Page 1 Manual Variable speed 0.7 Hp jig saw Power Applies for: Code Model 15420 CALA-A3 CALA-A3 Read this manual thoroughly CAUTION before using the tool.
  • Page 2: Table Of Contents

    Contents CAUTION Technical data Power requirements To gain the best performance of the tool, prolong the duty life, General power tool safety warnings make the Warranty valid if necessary, and to avoid hazards Safety warnings for jig saws of fatal injuries please read and understand this Manual before Parts using the tool.
  • Page 3: Technical Data

    Technical data CALA-A3 Code 15420 Description Variable speed jig saw Voltage 127 V Frequency 60 Hz Current 4.5 A Power 0.7 Hp Speed 0 strokes / min – 3 000 strokes / min (SPM) Miter cutting 0° - 45° left / right Cutting capacity Wood 2-1/2”...
  • Page 4: General Power Tool Safety Warnings

    General power tool safety warnings WARNING! Read carefully all safety warnings and instructions listed below. Failure to comply with any of these warnings may result in electric shock, fire and / or severe damage. Save all warnings and instructions for future references.
  • Page 5: Safety Warnings For Jig Saws

    Safety warnings for jig saws Select the adequate blade While operating the jig saw CAUTION CAUTION • Select the adequate blade for the • Hold the tool by the insulated griping material. Reduce the risk of severe personal injury and parts when there is risk of making contact with hidden make the job faster.
  • Page 6: Parts

    Parts Lock-on button Handle Speed Control Allen Switch Pendular Action Control Power Cord Protector Power Cord Blade Support Protection Cover Dust collector Base Plate Roller Guide Cutting Angle Adjusting Screws Parallel guide Preparation Blade installation • The opening of the blade support shall be free of sawdust. •...
  • Page 7 • Connect the extraction hose to the dust extraction port of the machine with an internal diameter of 1 3/8” (35 mm) (not compatible with Truper brand vacuums). • Connect the dust extraction hose to a dust extractor or vacuum cleaner.
  • Page 8: Start Up

    Start up Start up and operation control • Intermittent Operation: Connect the plug to the electrical outlet. Press the switch (A) to start the jig saw operating. To interrupt its use, simply release the switch. • Continuous Operation: Connect the plug to the electrical outlet. Press the switch (A) and lock it by pressing the continuous use button (B).
  • Page 9 Start up Cut wood sheets Straight cut • When cutting most wood sheets or very thin wood use • To make more accurate straight cuts, use the parallel a blade with fine teeth. Reduce splinters in the edges. • guide provided with the tool by resting it against the edge Clamp scrap pieces of wood onto both faces of the work of the workpiece.
  • Page 10: Maintenance

    Maintenance Carbon brush replacement WARNING Disconnect the tool from the power source before making adjustments, service o maintenance to the jig • Carbon brushes need to be checked regularly and when saw. worn, replaced in a Authorized Cleaning and care Service Center.
  • Page 11: Authorized Service Centers

    Authorized service centers In the event of any problem contacting a Truper Authorized Service Center, please see our webpage www.truper.com to get an updated list, or call our toll-free numbers 800 690-6990 or 800-018-7873 to get information about the nearest Service Center.
  • Page 12: Warranty

    It includes the costs of transportation of the product that derive from its fulfillment of its service network. Phone number 800-018-7873. Made in China. Imported by Truper, S.A. de C.V. Parque Industrial 1, Parque Industrial Jilotepec, Jilotepec, Edo. de Méx. C.P. 54257, Phone number 761 782 9100.
