Summary of Contents for Truper PRO LIMI-20A2
- Page 1 Manual Cordless impact wrench 13 mm 20 V 1/2” Chuck Applies for: Codes Models 103251 LIMI-20A2 103252 LIMI-20AS LIMI-20A2 Read this manual thoroughly CAUTION before using the tool.
- Page 2 They might be different from the real tool. Use and care recommendations Use the provided charger or the one suggested by TRUPER to charge the battery. Follow the battery usage considerations (page 7 and 9). Follow the instructions for operation and functions (page 10 - 12).
-
Page 3: Technical Data
Avoid the risk of electric shock or severe injury. When the power cable gets damaged it should only be replaced by the manufacturer or at a TRUPER Authorized Service Center. The build quality of the electric insulation is altered if spills or liquid gets into the tool while in use. - Page 4 General safety warnings for electric tools WARNING! Read all safety warnings, instructions, illustrations, and specifications provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire, and/or serious injury. Keep all warnings and instructions for future reference. The term 'power tool' in the warnings refers to your corded (plugged into an electrical outlet) or cordless (battery-operated) power tool.
-
Page 5: Safety Warnings
Use and care of the battery-powered tool Only recharge with the charger specified by TRUPER. Do not expose a battery pack or tool to fire or excessive Using the charger specified for one battery with another battery can cause temperatures. - Page 6 • Recharge only with the charger specified by TRUPER. Do conductive materials. When the battery pack is not in use, not use any charger that is not specifically provided for use keep it away from other metallic objects, such as paper with the equipment.
-
Page 7: Additional Safety Instructions For Your Battery Charger
Safety warnings for the battery charger WARNING! Read all safety warnings and all instructions. Failure to follow warnings and instructions can result in electric shock, fire, and/or serious injury. Keep all warnings and instructions for future reference. • This appliance is not intended for use by persons (including children) with reduced physical, sensory, or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning the use of the appliance by a person responsible for their safety. - Page 8 Parts Chuck Retaining Forward / reverse ring button ON/OFF switch Soft grip handle Safety strap 3-level variable speed control button light Belt clip Baterry release button Baterry (only included in LIMI-20A2) Baterry teeth terminals Charger (included only in LIMI-20A2) Charging *Battery and charger sold separately, only indicator included for this model LIMI-20A2...
-
Page 9: Battery Charging
Start up NOTE: Before using the tool, carefully read the instruction manual. The machine is intended for screwing and unscrewing. Battery charging WARNING The charger and batteries are 3. Your new tool's battery is not charged when it leaves specifically designed to work together, so do not attempt to the factory. - Page 10 • Always use impact sockets for this tool. Do not use sockets for hand tools. Refer to the TRUPER Catalog for our range of accessories. • Use sockets for a 1/2” (13 mm) square drive.
-
Page 11: Switch On/Off
Start up Switch on/off Press the on/off switch to start and release it to stop the tool. The on/off switch is equipped with a brake function that immediately stops the chuck when you quickly release the switch. It is also a variable speed switch that provides higher speed and torque with increased pressure on the trigger. -
Page 12: Belt Clip Assembly
Start up Variable speed with 3 levels Belt clip assembly Press the red button to select your preferred rotation • Remove the screw (A) fixed to the base of the tool. speed, levels 1 to 3, with 3 being the fastest. The •... -
Page 13: Troubleshooting
Troubleshooting Problem Cause Corrective action The tool loses • Low battery. • Charge the battery. effectiveness. The trigger cannot • The direction of rotation switch • Move the direction of rotation switch be pressed. is in the locked position. to the forward or reverse position. The trigger can be •... -
Page 14: Maintenance
• Remove the battery before adjusting, servicing, or Tool servicing should only be carried out at an Authorized maintenance. TRUPER Service Center. Servicing and maintenance • There are no user-serviceable parts in your power tool. performed by unqualified persons can be dangerous and •... -
Page 15: Authorized Service Centers
Authorized service centers In the event of any problem contacting a TRUPER Authorized Service Center, please see our webpage WWW.TRUPER.COM to get an updated list, or call our toll-free numbers 800 690-6990 or 800 018-7873 to get information about the nearest Service Center. -
Page 16: Warranty Policy
It includes the costs of transportation of the product that derive from its fulfillment of its service network. . Phone number 800-018-7873. Made in China. Imported by TRUPER, S.A. de C.V. Parque Industrial 1, Parque Industrial Jilotepec, Jilotepec, Edo. de Méx. C.P. 54257, Phone number 761 782 9100.
