- Page 1 Manual Benchtop jointer 1 500 W 2 Hp Applies for: Code Model 102973 CANT-6B CANT-6B Read this manual thoroughly CAUTION before using the tool.
-
Page 2: Table Of Contents
Parts list using the tool. Assembly Keep this manual for future references. Parts The illustrations in this manual are for reference Adjustments only. They might be different from the real tool. Start-up Maintenance Notes Authorized Service Centers Warranty Policy CANT-6B ENGLISH... -
Page 3: Technical Data
Technical data CANT-6B Code 102973 Description Benchtop jointer Voltage 127 V Current 12 A Frequency 60 Hz No-load speed 20 000 RPM Cutting head speed 10 000 RPM Weight 61.7 lb Dimensions Length: 28 1/2” | Width: 6” | Height: 8”... -
Page 4: General Safety Warnings For Power Tools
General power tool safety warnings WARNING! Read carefully all safety warnings and instructions listed below. Failure to comply with any of these warnings may result in electric shock, fire and / or severe damage. Save all warnings and instructions for future references. -
Page 5: Safety Warnings For The Use Of Jointers
Safety warnings for jointers Before operating the jointer Additional caution measures CAUTION • Seek for training from a qualified WARNING • DO NOT ASSEMBLE the tool until you operator familiar with the tool and it’s functioning. double-check it is not connected and the power switch is in CAUTION •... -
Page 6: Parts List
Parts list Work • Unpack the equipment and check for any table Guard damage during transport. • Clearly identify the individual parts as shown in the parts list. 1. Benchtop jointer. Switch with 2. Fence guide. lock 3. Limit block. 4. -
Page 7: Assembly
Assembly • Assemble the equipment in the location where it will be operated, on a well-leveled and weight-capable stand or base. The area should have good lighting and ventilation. • The equipment includes all the necessary screws for assembly, as well as a set of Allen and Torx keys in the required sizes for assembly. - Page 8 Assembly Fence guide hinge • Slide the hinge assembly into the base of the fence guide (A). Ensure that the assembly fits into the dovetail on the base and the locking plate. • Push the hinge pin (B) to insert the limit block (C) with the notched side facing up.
- Page 9 Assembly Fence guide • Use two M6 head screws and two 6 mm lock washers to attach the fence guide to the hinge (E). • Adjust the guide to be at 90° and tighten the angle Dust extraction system connector locking lever (F).
-
Page 10: Parts
Parts Cutting Fence head Extraction table Fence and hinge support joint Feed table Antivibration base Feed Feed table table height control knob Guard Switch lock Cut depth scale Guide support Limit block angle locking securing bolt lever Power cord Extraction table Limit block locking lever of fence depth... -
Page 11: Adjustments
Adjustments Feed table height • To adjust the height of the feed table, turn the feed table adjustment knob (A) to raise or lower the table. • To determine the table height, check the depth scale (B). Feed table height stop •... - Page 12 Adjustments Blade adjustment • To ensure accurate edging and ATENCIÓN prevent defective work, the blades must be perfectly aligned and leveled with the surface of the extraction Extraction Inlet table. table table • Before adjusting the blades, remove the cutting head guard and lower the feed table as indicated above.
- Page 13 Adjustments Fence guide stops adjustment • The fence guide tilting system has stops for quickly selecting angles of ±45° and 90°. Use a combination square to check them. If the angles are incorrect, you can adjust the stops. • 90° Stop: Push the knob (C) forward and pull the limit block to secure it in its first slot (D).
-
Page 14: Start-Up
Start-up Power On • Plug the jointer to the power outlet. • Lift the lever to turn on the jointer. • Lower the lever to turn off the jointer. • To prevent accidental starts, remove the key to disable the switch. Workpiece 254 mm (10”) •... -
Page 15: Maintenance
Carbon brush replacement • The carbon brushes should be periodically checked and replaced by an Authorized Truper Service Center when worn out. After replacement, request an inspection to ensure that the new carbon brushes can move freely in the brush holder and ask them to run the tool for 15 minutes to seat the carbon brush contact and the commutator. -
Page 16: Notes
Notes ENGLISH... -
Page 17: Authorized Service Centers
Authorized Service Centers In the event of any problem contacting a Truper Authorized Service Center, please see our webpage www.truper.com to get an updated list, or call our toll-free numbers 800 690-6990 or 800-018-7873 to get information about the nearest Service Center. -
Page 18: Warranty Policy
It includes the costs of transportation of the product that derive from its fulfillment of its service network. Phone number 800-018-7873. Made in China. Imported by Truper, S.A. de C.V. Parque Industrial 1, Parque Industrial Jilotepec, Jilotepec, Edo. de Méx. C.P. 54257, Phone number 761 782 9100.
