JBL 125 SAT Technical Manual

Technical Manual
125 SAT
(Satellite for SCS125/SCS125a)
ACOUSTIC & ELECTRICAL SPECIFICATIONS
• Nominal Impedance
• Max Amp Power
• Frequency Response
• Sensitivity

SYSTEM COMPONENTS:

• Cabinet
• Grille
• Low Frequency Transducer 3" Shielded Midrange
DC Resistance
• High Frequency Transducer 1/2" Dome Tweeter
DC Resistance
• Crossover Network

PACKAGING

Owner's Manual
AI0360
125SAT Speakers
SAT 125
Mural Stand
WI0409
Outer Carton
WB1782
Optional 125SAT Speaker Stands:FS300
JBL Incorporated
All manuals and user guides at all-guides.com
8 ohms
50 watts
200Hz – 20kHz
86 dB, 1 watt @ 1 meter
125SAT (Not for sale)
G02005-B
(N68A45PF-02DW)
4.0 ohms ±10%
(Not Replaceable)
( )Piezo Design
125SAT (Not Available)
Warranty Card
AI0193
Plastic Bag
Wall Hook
Foam Set
WI0408
WP0344
SUB125
250 Crossways Park Dr.

AURAL SWEEP TEST SPECIFICATIONS:

• System Aural Sweep Test
• L.F. Aural Sweep Test
• H.F. Aural Sweep Test

PHYSICAL SPECIFICATIONS

• Enclosure dimensions:

SHIPPING WEIGHT:

• 1 lbs. (.45 kg) part of the SCS125/SCS125a

WARRANTY:

• Refer to Warranty Statement packed with each product.

WIRING DIAGRAM

+
DRIVER
HIGH FREQUENCY
–
–
+
LOW FREQUENCY
N68A45PF-02DW

125 SAT SCHEMATIC

Polyswitch
+
Input
6 Ω
10W
–
Woodbury, New York 11797
4.0V Input 200 Hz to 20 kHz
4.0V Input 200 Hz to 12 kHz
2.0V Input 8 kHz to 20 kHz
4 3/8" x 3 3/16" x 3 3/4"
(H x W x D)
RECEPTACLE
NETWORK
125SAT
(Not Available)
DRIVER
17µF 50V
RED
3Ω 5W
200 µF
50V
0.3 mH
BLK
RED
BLK
Rev1 12/2003
+
L.F.
–
+
H.F.
–
