  • Page 1 User Guide 020-002068-01 SUHD983-P-A LCD Panels...
  • Page 2 Christie's control such as maintenance of the product in proper working conditions. Performance specifications are based on information available at the time of printing. Christie makes no warranty of any kind with regard to this material, including, but not limited to, implied warranties of fitness for a particular purpose. Christie will not be liable for errors contained herein or for incidental or consequential damages in connection with the performance or use of this material.

  • Page 3: Table Of Contents

    Connecting a control system or PC ..................20 RS232 connection ......................20 SUHD983-P-A LCD Panels User Guide 020-002068-01 Rev. 1 (04-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.
  • Page 4 Powering the display on or off using a CEC command ............36 SUHD983-P-A LCD Panels User Guide 020-002068-01 Rev. 1 (04-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.
  • Page 5 Controlling monitor settings .................... 50 Maintenance and troubleshooting ............51 Maintenance ........................51 Troubleshooting ........................ 51 SUHD983-P-A LCD Panels User Guide 020-002068-01 Rev. 1 (04-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 6: Unpackaging And Handling The Display

    Remove any additional packaging, such as protective stickers, from the display panel. SUHD983-P-A LCD Panels User Guide 020-002068-01 Rev. 1 (04-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 7: Handling And Mounting Guidelines For Extreme Narrow Bezel Series Panels

    Product documentatinon For installation, setup, and user information, see the product documentation available on the Christie website. Read all instructions before using or servicing this product. 1. Access the documentation from the Christie website: Go th this URL: https://bit.ly/2VccFTr.

  • Page 8: Related Documentation

    Warning! If not avoided, the following could result in death or serious injury. • Christie products must be installed and serviced by Christie qualified technicians. Two people or adequately rated lifting equipment are required to safely lift, install, or move the •...

  • Page 9: Electrical Specifications

    The following symbols are used on the panels: I/O: On or off • • ~: Alternating current SUHD983-P-A LCD Panels User Guide 020-002068-01 Rev. 1 (04-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 10: Introduction

    Christie prepared this manual to help end users get the most out of the display. Christie has made every effort to ensure this guide is accurate as of the date it was printed. However, because of ongoing product improvements and customer feedback, it may require updating without notice from time to time.
  • Page 11 HDMI cable (length 3000 mm) • External IR Receiver kit • Screw (M3x6)—two each SUHD983-P-A LCD Panels User Guide 020-002068-01 Rev. 1 (04-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 12: Controls And Functions

    Use the keypad instead of the remote control unit to operate the on-screen display (OSD) On/Standby ( controls. SUHD983-P-A LCD Panels User Guide 020-002068-01 Rev. 1 (04-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.
  • Page 13 'M (MENU) exit the on-screen display and return to the previous one. SUHD983-P-A LCD Panels User Guide 020-002068-01 Rev. 1 (04-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 14: In/Output Panel

    Connects with USB device for software update. Service In (USB A type) SUHD983-P-A LCD Panels User Guide 020-002068-01 Rev. 1 (04-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 15: Remote Control Unit

    Turns on or off the product SOURCE Selects a connected source device SUHD983-P-A LCD Panels User Guide 020-002068-01 Rev. 1 (04-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.
  • Page 16 Direct Key Preset 8 Direct Key Preset 9 Direct Key Preset 10 SUHD983-P-A LCD Panels User Guide 020-002068-01 Rev. 1 (04-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 17: Installing The Display

    The remote control may fail to operate if the infrared remote sensor is exposed to bright sunlight or fluorescent lighting. SUHD983-P-A LCD Panels User Guide 020-002068-01 Rev. 1 (04-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 18: Quick Setup: Workflow

    This allows heat to disperse, maintaining the proper operating temperature. SUHD983-P-A LCD Panels User Guide 020-002068-01 Rev. 1 (04-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 19: Mounting The Display

    If you decide to wall-mount the display, ensure the wall-mount bracket is installed according to the instructions included with it. The wall must be capable of supporting a multiple weight factor of three times the weight of the display or be reinforced. Christie recommends this be done by a custom installation specialist.

  • Page 20: Connecting A Control System Or Pc

    Connect the provided External IR Receiver kit to the IR input as shown below. SUHD983-P-A LCD Panels User Guide 020-002068-01 Rev. 1 (04-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 21: Connecting Source Components To The Display

    VESA DDC-compatible computer communicate their setting requirements, allowing for quick and easy setup. SUHD983-P-A LCD Panels User Guide 020-002068-01 Rev. 1 (04-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 22: Hdmi Source Connections

    For plug-and-play to work correctly, turn on the display before you turn on the connected computer. SUHD983-P-A LCD Panels User Guide 020-002068-01 Rev. 1 (04-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.
  • Page 23 DVI-D Cable (Sold Separately) SUHD983-P-A LCD Panels User Guide 020-002068-01 Rev. 1 (04-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 24: Turning On The Power

    4. If the power indicator is red not green, select the Power button on the remote control or on the keypad to turn on the power. Avoiding image retention Christie recommends doing the following to prolong the life of the display: Operate the display within its rated ambient environment •...

  • Page 25: Operation

    0 to 100 Color Temperature Normal Normal Normal Warm Cool Studio1 Studio2 User SUHD983-P-A LCD Panels User Guide 020-002068-01 Rev. 1 (04-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.
  • Page 26 OPS-RS232t FRC Mode Free run Lock Free run Free run CEC Control SUHD983-P-A LCD Panels User Guide 020-002068-01 Rev. 1 (04-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.
  • Page 27 Triple3/DP1/DP2/HDMI1 Preset19 — Triple4/DP1/DP2/HDMI1 Preset20 — Quad/DP1/DP2/ HDMI1/HDMI2 Preset Reset — — SUHD983-P-A LCD Panels User Guide 020-002068-01 Rev. 1 (04-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.
  • Page 28 — — Specifications are subject to change without notice to improve quality. SUHD983-P-A LCD Panels User Guide 020-002068-01 Rev. 1 (04-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 29: Picture Settings

    Brightness, Contrast, and other settings manually. Setting image contrast Contrast adjusts the white levels of the image. SUHD983-P-A LCD Panels User Guide 020-002068-01 Rev. 1 (04-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 30: Seting Image Brightness

    Contrast and Black Level controls are interactive. A change to one may require a subtle change to the other to achieve the optimum setting. SUHD983-P-A LCD Panels User Guide 020-002068-01 Rev. 1 (04-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 31: Setting Image Color

    Lower the sharpness setting to eliminate them. SUHD983-P-A LCD Panels User Guide 020-002068-01 Rev. 1 (04-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 32: Setting Image Color Temperature

    2. Enable or disable the control. Resetting the picture values Reset all values in the Picture menu. SUHD983-P-A LCD Panels User Guide 020-002068-01 Rev. 1 (04-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 33: Sound Settings

    2. Adjust the Balance using the slider bar in the range of -50 to +50. OSD settings The following shows the OSD settings. SUHD983-P-A LCD Panels User Guide 020-002068-01 Rev. 1 (04-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 34: Specifying The Language

    • C: Center • BL: Bottom Left • BR: Bottom Right • SUHD983-P-A LCD Panels User Guide 020-002068-01 Rev. 1 (04-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 35: Determining The On-Screen Display Rotation

    Mode control control control consumption Standby Under 5W Deep Sleep Under 0.5W SUHD983-P-A LCD Panels User Guide 020-002068-01 Rev. 1 (04-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 36: Selecting The Movie Mode

    2. Select the EDID for the OPS/HDMI4. Valied values: UHD or FHD. SUHD983-P-A LCD Panels User Guide 020-002068-01 Rev. 1 (04-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 37: Determining The Gamma Curve

    From the Setup menu, select Factory Reset. All settings, including image settings are restored to their factory defaults. SUHD983-P-A LCD Panels User Guide 020-002068-01 Rev. 1 (04-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 38: Presets

    Preset8 Triple3/HDMI1/HDMI2/HDMI3 Preset9 Triple4/HDMI1/HDMI2/HDMI3 Preset10 Quad/HDMI1/HDMI2/HDMI3/HDMI4 Preset11 One /DP1 Preset12 Dual1 /DP1/DP2 SUHD983-P-A LCD Panels User Guide 020-002068-01 Rev. 1 (04-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 39: Resetting Presets

    1. From the Preset menu, select Modes. 2. Select an input source. SUHD983-P-A LCD Panels User Guide 020-002068-01 Rev. 1 (04-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 40: Viewing Status Information

    OPS- HDMI OPS-DP Viewing status information The following shows the status information. SUHD983-P-A LCD Panels User Guide 020-002068-01 Rev. 1 (04-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 41: Open Plugable Specification (Ops)

    80 pin JAE plug and receptacle connectors. SUHD983-P-A LCD Panels User Guide 020-002068-01 Rev. 1 (04-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.
  • Page 42 The connector series image is for reference only. • Left: Plug connector (P/N: TX25A-80P-LT-H1E). Right: Receptacle connector (P/N: TX24A-80R-LT-H1E). SUHD983-P-A LCD Panels User Guide 020-002068-01 Rev. 1 (04-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 43: Supported Timings

    RGB/4:4:4 8/10/12bpc 7680x4320 7680 4320 RGB/4:4:4 8/10/12bpc OPS HDMI, 640x480 RGB/4:4:4/4:2:2 8/10/12bpc SUHD983-P-A LCD Panels User Guide 020-002068-01 Rev. 1 (04-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.
  • Page 44 8/10/12bpc 1920x1080 1920 1080 RGB/4:4:4/4:2:2 8/10/12bpc 3840x2160 3840 2160 30,60 RGB/4:4:4/4:2:2 8/10/12bpc SUHD983-P-A LCD Panels User Guide 020-002068-01 Rev. 1 (04-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 45: Updating Scaler Firmware Using Usb

    You cannot enter Factory-Menu when set to Multi-Windows mode. You must change Multi-Window mode to off to enter Factory-Menu. • SUHD983-P-A LCD Panels User Guide 020-002068-01 Rev. 1 (04-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.
  • Page 46 Regradless of software version, the filename must always be SUHD983P.bin to upload correctly. SUHD983-P-A LCD Panels User Guide 020-002068-01 Rev. 1 (04-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 47: Network Guide

    If there is no router, the IP address starts with 169.254. • SUHD983-P-A LCD Panels User Guide 020-002068-01 Rev. 1 (04-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 48: Pc Setting

    1. In a web browser, go to the address of the display panel. SUHD983-P-A LCD Panels User Guide 020-002068-01 Rev. 1 (04-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 49: Upgrading The Ethernet Or Scaler Firmware

    4. Control the monitor settings, for example, the Picture setting and remote control. SUHD983-P-A LCD Panels User Guide 020-002068-01 Rev. 1 (04-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 50: Connecting To The Crestron-Roomview Program

    Controlling monitor settings You can control monitor settings, such as adding various attributes. SUHD983-P-A LCD Panels User Guide 020-002068-01 Rev. 1 (04-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.

  • Page 51: Maintenance And Troubleshooting

    Black level and/or brightness are • Increase the black level and/or set too low. brightness settings. SUHD983-P-A LCD Panels User Guide 020-002068-01 Rev. 1 (04-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.
  • Page 52 43). display. • The Clock and Phase settings need adjustment. SUHD983-P-A LCD Panels User Guide 020-002068-01 Rev. 1 (04-2023) Copyright 2023 Christie Digital Systems USA, Inc. All rights reserved. © If printed, please recycle this document after use.
