Operations
The unit is in Power Off Status:
Press the 2 (Illumination Switch) button, you can turn off the X-breath
illumination.
4
Power Indicator
When the unit turned on, the 3 (power indicator) indicator lights up.
5
Front Equalizer Level & Frequence Adjustment
Adjust F1-L, F2-L, F3-L buttons to change the equalizer level of each
band.
Adjust F1-F, F2-F, F3-F buttons to change the equalizer center
frequence of each band.
LEVEL ADJUST CURVE
6
Rear Equalizer Level & Frequence Adjustment
Adjust R1-L, R2-L, R3-L buttons to change the equalizer level of each
band.
Adjust R1-F, R2-F, R3-F buttons to change the equalizer center
frequence of each band.
g
(d B)
15
12
9
6
3
f
0
-3
-6
-9
-1 2
-1 5
(Hz )
0
CENTER FREQUENCE ADJUSTCURVE
g
(d B)
f1
f
(Hz )
f2
