INSTALLATION
The following illustration shows a typical installation. However, you should
make adjustments corresponding to your specific car. If you have any
questions or require information regarding installation kits, consult your car
audio dealer or a company supplying kits.
1
In-dash single mounting
Frame
2
Compound with other head-unit to a 2-din size system
Screws(M5x6mm)
-2-
Screws(M5x10mm)
Dashboard
Bracket
Frame
Screws(M5x10mm)
Mounting bolt
Bracket
Bracket
Bracket
Lock nut
(M5)
Stay
Screws(M5x6mm)
