Operations

F1-L
FRONT
dB -15 +15
LEVEL
30-150
Hz
Low
F R E Q
F1-F
1
Turn On/Off the unit
When you connect the Remote On lead, the unit will be turned
automatically on/off following the audio source equipment.
2
Adjust Buttons Position Switch
Press the 1 (Adjust Buttons Position Switch) button, the Adjust buttons
move forward for further adjustment. Press the 1 (Adjust Buttons Position
Switch) button again, the Adjust buttons move back to the normal position
to prevent accidental adjustment.
When the unit turned off, the Adjust buttons move back to the normal
position automatically.
3
Illumination Switch
The unit is in Power On Status:
Press the 2 (Illumination Switch) button, the illumination modes change
as follows:
-6-
F2-L F3-L
-15 +15 -15 +15
300-1.5K 3K-15K
Hi Low Hi Low Hi
F2-F F3-F
X-Breath mode(Dual color)
4
3
POWER ON
SLEEP
Min Max Min
GAIN GAIN
LEVEL FREQ
MIN MAX 30 Hz 180
SUB-Woofer
ADJ ADJ
Control
1
Blue color mode
R1-L R2-L
Max -15 +15 -15 +15
30-150 300-1.5K
Low Hi Low
PWM-30M
ILL ILL
Parametric Equalizer
R1-F R2-F
2
Red color mode
R3-L
REAR
-15 +15 dB
LEVEL
3K-15K
Hz
Hi Low Hi
F R E Q
R3-F
