LOCATION OF THE BUTTONS

F1-L
FRONT
dB -15 +15
LEVEL
30-150
Hz
Low Hi Low
F R E Q
F1-F
F1-L
Front Band 1 Level Adjust Button
F2-L
Front Band 2 Level Adjust Button
F3-L
Front Band 3 Level Adjust Button
F1-F
Front Band 1 Frequence Adjust Button
F2-F
Front Band 2 Frequence Adjust Button
F3-F
Front Band 3 Frequence Adjust Button
F4
Front Gain Adjust Button
R1-L
Rear Band 1 Level Adjust Button
R2-L
Rear Band 2 Level Adjust Button
R3-L
Rear Band 3 Level Adjust Button
R1-F
Rear Band 1 Frequence Adjust Button
R2-F
Rear Band 2 Frequence Adjust Button
R3-F
Rear Band 3 Frequence Adjust Button
R4
Rear Gain Adjust Button
F2-L F3-L
-15 +15 -15 +15 Min
300-1.5K 3K-15K
Hi Low Hi
ADJ ADJ
F2-F
F3-F
1
4
3
F4 R4
POWER ON
SLEEP
Max Min Max
GAIN GAIN
FREQ
LEVEL
MIN MAX 30 180
Hz
SUB-Woofer
ILL ILL
Control
S2 S1 S3
5 2
R1-L R2-L
-15 +15 -15 +15
30-150 300-1.5K
Low Hi Low Hi Low
PWM-30M
Parametric Equalizer
R1-F R2-F
S-1
SUB-Woofer Control
Button
S-2
Subwoofer Level Adjust
Button
S-3
Subwoofer Frequence
Adjust Button
1
Adjust Buttons Position
Switch
2
Illumination Switch
3
Power Indicator
4
Sleep Indicator
5
Subwoofer On/Off
Switch
R3-L
REAR
-15 +15 dB
LEVEL
3K-15K
Hz
Hi
F R E Q
R3-F
