Operations
FRONT
dB -15
LEVEL
30-150
Hz
Low
F R E Q
7
(Front Channel) Gain Control
Adjusting F4 (Front Gain Adjust) button can change the front channel
amplifier gain level to fit your system input and output level demand.
8
(Rear Channel) Gain Control
Adjusting R4 (Rear Gain Adjust) button can change the rear channel
amplifier gain level to fit your system input and output level demand.
9
SUB-woofer Control
Press the S1 (SUB-woofer Control) button to turn on /off the SUB-
woofer output.
Adjust the S2 (SUB-woofer Level) button to change the SUB-woofer
gain level
Adjust the S2 (SUB-woofer Level) button to change the SUB-woofer
cut-off frequence.
